  • LS-SMV1228P-6M dimensions (mm)

Machine vision lenses

12 mm, 2/3", 6 MP, C-mount Machine Vision Lens (LS-FFL-0658)

Model LS-FFL-0658

  • Focal length12 mm
  • MountC-mount
  • Sensor2/3"
  • ApertureF2.8 Manual iris
  • Resolution6.0 Megapixel (2.4μm pixel size)
$179.00

In stock - ships the same business day (5 available, order by 2 PM ET)

0.18 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

12 mm, 2/3", 6 MP, C-mount Machine Vision Lens (LS-FFL-0658)LS-FFL-0658

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

12 mm, 2/3", 6 MP, C-mount Machine Vision Lens. 2/3" 6 megapixel C-mount machine vision lenses for 2.4 um pixel sensors, F2.8 manual iris, 12 to 50 mm, transmission T>=85% at 486-656 nm. At a glance: focal length 12 mm; format 2/3"; resolution 6.0 Megapixel (2.4μm pixel size); aperture F2.8 Manual iris; mount C.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-FFL-0658
Format2/3"
Angle of view (2/3", DxHxV)48 x 39 x 30 deg
TransmissionAT486~656nm T≥85%
CRA6°
Notes8G Element

Optics

Focal length12 mm
ApertureF2.8 Manual iris
M.O.D.0.1 m
Distortion (optical)1.2%
Filter threadM27 x P0.5
Relative illumination68%
Total track length (TTL)58.78 mm
Back focal length14.13 mm

Sensor and imaging

Resolution6.0 Megapixel (2.4μm pixel size)

Mechanical

MountC
Sizedia. 33 x 41.2 mm
Weight60 g
Shipping weight (estimated)0.18 kg

Photo shows a representative model of this series; see the specifications for this model.
