Light controllers
Digital constant-voltage light controller, 150W, 1 channel @ 12M-2B connector (LS-LEVD-150-1B-PY)
Model LS-LEVD-150-1B-PY
Digital constant-voltage light controller, 150W, 1 channel @ 12M-2B connector. Up to 6.25 A output current per channel 3 brightness control methods: panel knob, panel buttons and serial communication
Features
- Up to 6.25 A output current per channel
- 3 brightness control methods: panel knob, panel buttons and serial communication
- Serial control provides 256 brightness levels (0–255)
- High-speed optocoupler-isolated external trigger for accurate, highly reliable trigger signals
- Power-loss memory and overload/short-circuit protection
Specifications
| Model | LS-LEVD-150-1B-PY |
|---|---|
| Drive mode | Constant voltage |
| Lighting mode | Constant voltage |
| PWM frequency | Not supported |
| Strobe overdrive | Not supported |
| Channel | 1 |
| Dimming mode | Panel knob, Serial communication |
| Brightness level | 0 ~ 255 |
| Lighting response time | Not supported |
| Trigger mode | Not supported |
| Communication protocol | Not supported |
| Applicable product | Large panel light, Standard line light |
| Input voltage | 24 VDC |
| Input current | 1 A |
| Output current | 6.25 A max |
| Output power | 150 W max |
| Output current for each channel | 6.25 A max |
| Trigger in | Not supported |
| Trigger out | Not supported |
| Power supply interface | AC socket |
| Console interface | Serial port |
| Digital I/O | Not supported |
| Lighting output connector | 12M-2B; SMR-03V-BC |
| Dimension | 309.3 mm × 115 mm × 111 mm |
| Shell material | Galvanized steel sheet |
| Weight | Approx. 2160 g |
| Temperature | Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F) |
| Ingress protection | IP30 (when properly installed) |
| Humidity | 20% RH to 85% RH (no condensation) |
| Cooling mode | Forced cooling (built-in fan) |
| Certification | CE, RoHS |
| Shipping weight (estimated) | 3.12 kg |
Complete the station
The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.
