Area scan cameras
Hikrobot MV-DV2592-300GM 5 MP 1/2.5" Gigabit Ethernet industrial area scan camera
Model MV-DV2592-300GMHikrobot
- Resolution2592 × 1944
- SensorCMOS, rolling shutter
- Speed23.1 fps @2592 × 1944 Mono8
- Lens mountC-mount
- Mono / colourMono
- Pixel size2.2 μm × 2.2 μm
$819.00
Ships in 2-3 weeks
0.24 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-DV2592-300GM 5 MP 1/2.5" Gigabit Ethernet industrial area scan camera. Optimized hardware design: stable performance and low power consumption Automatic and manual adjustment of gain, exposure time and other parameters
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-DV2592-300GM |
|---|---|
| Brand | Hikrobot |
| Compatibility | GigE Vision V2.0, GenlCam |
Sensor and imaging
| Sensor type | CMOS, rolling shutter |
|---|---|
| Pixel size | 2.2 μm × 2.2 μm |
| Sensor size | 1/2.5'' |
| Resolution | 2592 × 1944 |
| Max. frame rate | 23.1 fps @2592 × 1944 Mono8 |
| Dynamic range | 70.2 dB |
| SNR | 40.8 dB |
| Gain | 0 dB ~ 24 dB |
| Exposure time | 24 μs ~ 2.5 sec |
| Exposure mode | Off/Once/Continuous exposure mode |
| Mono/color | Mono |
| Pixel format | Mono 8/10/10Packed/12/12Packed |
| Binning | Supports 1 × 1, 2 × 2 |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 |
| Reverse image | Supports horizontal and vertical reverse image output |
Interfaces and I/O
| Data interface | Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s) |
|---|---|
| Digital I/O | 6-pin P7 connector provides power and I/O: 1 opto-isolated input (Line 0), 1 opto-isolated output (Line 1), 1 bidirectional configurable non-isolated I/O (Line 2) |
| Client software | MVS or third-party software meeting with GigE Vision Protocol |
Environment and compliance
| Ingress protection | IP30 (under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | RoHS, CE, KC |
Computing
| Operating system | Windows XP/7/10/11 32/64bits, Linux 32/64bits, MacOS 64bits |
|---|
Electrical
| Power supply | 9 VDC to 24 VDC, PoE is optional |
|---|---|
| Power consumption | 2.5 W@12 VDC |
Mechanical
| Lens mount | C-Mount |
|---|---|
| Dimension | 29 mm × 29 mm × 42 mm |
| Weight | Approx. 100 g (0.2 lb.) |
| Shipping weight (estimated) | 0.24 kg |
