Area scan cameras
Hikrobot MV-CU060-60GM(NPOE) 6 MP GigE area scan camera, Mono, Without PoE
Model MV-CU060-60GM(NPOE)Hikrobot
- Resolution3200 × 1944
- SensorCMOS, rolling shutter
- Speed19 fps@3200 × 1944 Mono 8
- Lens mountC-mount
- Mono / colourMono
- Pixel size2 μm × 2 μm
$489.00
Ships in 2-3 weeks
0.24 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CU060-60GM(NPOE) 6 MP GigE area scan camera, Mono, Without PoE. Optimized hardware design: stable performance and low power consumption Automatic and manual adjustment of gain, exposure time and other parameters
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CU060-60GM(NPOE) |
|---|---|
| Brand | Hikrobot |
| Compatibility | GigE Vision 2.0, GenlCam |
Sensor and imaging
| Sensor type | CMOS, rolling shutter |
|---|---|
| Sensor model | BSI |
| Pixel size | 2 μm × 2 μm |
| Sensor size | 1/2.4'' |
| Resolution | 3200 × 1944 |
| Max. frame rate | 19 fps@3200 × 1944 Mono 8 |
| Dynamic range | 64 dB |
| SNR | 33.8 dB |
| Gain | 0 dB ~24 dB |
| Exposure time | 52 μs ~ 10 s |
| Exposure mode | Off/Once/Continuous exposure mode |
| Mono/color | Mono |
| Pixel format | Mono 8/10/10Packed/12/12Packed |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 |
| Reverse image | Supports horizontal and vertical reverse image output |
Interfaces and I/O
| Data interface | Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s) |
|---|---|
| Digital I/O | 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). |
| Client software | MVS or third-party software meeting with GigE Vision Protocol |
Environment and compliance
| Ingress protection | IP30 (under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | RoHS, CE, KC |
Computing
| Operating system | Windows 7/10/11 32/64bits, Linux 32/64bits |
|---|
Electrical
| Power supply | 9 VDC to 24 VDC, PoE is optional |
|---|---|
| Power consumption | 1.6 W@12 VDC |
Mechanical
| Lens mount | C-Mount |
|---|---|
| Dimension | 29 mm × 29 mm × 42 mm |
| Weight | Approx. 100 g (0.2 lb.) |
| Shipping weight (estimated) | 0.24 kg |
