Hikrobot MV-CU050-30GC(NPOE) V2 5 MP GigE area scan camera, AR0521, Color, Without PoE
  • Hikrobot MV-CU050-30GC(NPOE) V2 5 MP GigE area scan camera, AR0521, Color, Without PoE
  • MV-CU050-30GC(NPOE) V2 dimensions (mm)

Area scan cameras

Hikrobot MV-CU050-30GC(NPOE) V2 5 MP GigE area scan camera, AR0521, Color, Without PoE

Model MV-CU050-30GC(NPOE) V2Hikrobot

  • Resolution2592 × 1944
  • SensorCMOS, rolling shutter
  • Speed24 fps @ 2592 × 1944 Bayer GR 8
  • Lens mountC-mount
  • Mono / colourColor
  • Pixel size2.2 μm × 2.2 μm
$449.00

Ships in 2-3 weeks

0.24 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineerBrowse Area scan cameras

MV-CU050-30GC(NPOE) V2: resolution 2592 x 1944; sensor type CMOS, rolling shutter; sensor size 1/2.5''; dynamic range 63 dB; power consumption 1.81 W @ 12 VDC.

Hikrobot MV-CU050-30GC(NPOE) V2 5 MP GigE area scan camera, AR0521, V2, Color, Without PoE. Optimized hardware design: stable performance and low power consumption. Automatic and manual adjustment of gain, exposure time and other parameters.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)RoHS

Specifications

General

ModelMV-CU050-30GC(NPOE) V2
BrandHikrobot
CompatibilityGigE Vision 2.0, GenICam

Sensor and imaging

Sensor typeCMOS, rolling shutter
Sensor modelAR0521
Pixel size2.2 μm × 2.2 μm
Sensor size1/2.5''
Resolution2592 × 1944
Max. frame rate24 fps @ 2592 × 1944 Bayer GR 8
Dynamic range63 dB
SNR37 dB
Gain0 dB ~ 15 dB
Exposure time21 μs ~ 1 sec
Exposure modeOff/Once/Continuous exposure mode
Mono/colorColor
Pixel formatBayer GR 8/10/10Packed/12/12Packed
BinningSupports 1 × 1, 2 × 2
DecimationSupports 1 × 1, 2 × 2
Reverse imageSupports horizontal and vertical reverse image output

Interfaces and I/O

Data interfaceGigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Digital I/O6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client softwareMVS or third-party software meeting with GigE Vision Protocol

Environment and compliance

Ingress protectionIP30 (under proper lens installation and wiring)
TemperatureWorking temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity20% RH to 80% RH (no condensation)
CertificationRoHS

Computing

Operating systemWindows 7/10/11 32/64bits, Linux 32/64bits

Electrical

Power supply9 VDC to 24 VDC, PoE is optional
Power consumption1.81 W @ 12 VDC

Mechanical

Lens mountC-Mount
Dimension29 mm × 29 mm × 42 mm
WeightApprox. 100 g (0.2 lb.)
Shipping weight (estimated)0.24 kg

Engineering data

Field of view and resolution with the MV-CU050-30GC(NPOE) V2

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area5.7 × 4.28 mm1/2.5" optical format
Lens image circle needed≥ Ø 7.1 mmC-mount
Pixel pitch2.2 µm2592 x 1944 px
Image data at max frame rate121 MB/sCalculated: 24 fps × 2592 × 1944 px at 8 bit · GigE carries 125 MB/s nominal
With a 16 mm lens at 500 mm178 × 134 mm0.069 mm per pixel
Dynamic range63 dB
SNR37 dB
Power consumption1.81 Wat 12 V DC
ShutterRolling
Exposure range21 µs to 1 s
Weight100 gapprox.
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm214 × 160 mm0.082 mm per pixel356 × 268 mm0.137 mm per pixel712 × 535 mm0.275 mm per pixel
12 mm142 × 107 mm0.055 mm per pixel238 × 178 mm0.092 mm per pixel475 × 357 mm0.183 mm per pixel
16 mm107 × 80.2 mm0.041 mm per pixel178 × 134 mm0.069 mm per pixel356 × 268 mm0.137 mm per pixel
25 mm68.4 × 51.4 mm0.026 mm per pixel114 × 85.6 mm0.044 mm per pixel228 × 171 mm0.088 mm per pixel
35 mm48.9 × 36.7 mm0.019 mm per pixel81.4 × 61.1 mm0.031 mm per pixel163 × 122 mm0.063 mm per pixel
50 mm34.2 × 25.7 mm0.013 mm per pixel57 × 42.8 mm0.022 mm per pixel114 × 85.6 mm0.044 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.
