Hikrobot MV-CH250-90VM 25MP Area Scan Camera, dual USB3.0, GMAX0505, Mono

Model MV-CH250-90VMHikrobot

Resolution5120 × 5120
SensorCMOS, global shutter
InterfaceUSB 3.0, compatible with USB 2.0
Speed30 fps @5120 × 5120 Mono 8
Lens mountC-mount
Mono / colourMono

$3,409.00

Quote

Ships in 2-3 weeks

0.24 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Available in the US - comparable cameras:

Hikrobot MV-CH250-90VM 25MP Area Scan Camera, dual USB3.0, GMAX0505, Mono. Supports manual adjustment of gain, LUT, Gamma correction, etc. Adopts dual USB 3.0 interfaces to transmit data.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CH250-90VM
Brand	Hikrobot
Compatibility	GenICam

Sensor and imaging

Sensor type	CMOS, global shutter
Sensor model	Gpixel GMAX0505
Pixel size	2.5 μm × 2.5 μm
Sensor size	1.1"
Resolution	5120 × 5120
Max. frame rate	30 fps @5120 × 5120 Mono 8
Dynamic range	65 dB
SNR	40 dB
Gain	2.0 x to 5.0 x
Exposure time	UltraShort exposure mode: 1 μs to 8 μs; Standard exposure mode: 9 μs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono/color	Mono
Pixel format	Mono 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2, 4 × 4
Decimation	Supports 1 × 1, 2 × 2, 4 × 4
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	USB 3.0, compatible with USB 2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS

Environment and compliance

Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –10 °C to 40 °C (14 °F to 104 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 95% RH, no condensation
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows XP/7/10/11

Electrical

Power supply	9 VDC to 24 VDC, supports USB 3.0 power supply
Power consumption	Typ. 4.8 W @ 5 VDC (dual USB 3.0 interfaces provide power supply)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 44 mm × 59 mm (1.1" × 1.7" × 2.3")
Weight	Approx. 100 g (0.2 lb.)
Shipping weight (estimated)	0.24 kg

Downloads

Features

Supports manual adjustment of gain, LUT, Gamma correction, etc.
Adopts dual USB 3.0 interfaces to transmit data.
Supports hardware trigger, software trigger, and free run.
Supports flexible installation via the installation holes.
Adopts compact design for small spatial installation.
Compatible GenlCam Standard.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer
