0.097x bi-telecentric lens, WD 465 mm, 1.75"
LS-TCL-1188
- Magnification 0.097x
- Mount F-mount
- Sensor 1.75"
$8,800.00Quote
Ships in 3-4 weeks
Lenses
1.75-inch telecentric lenses
Build a large-sensor measurement layoutCompare telecentric lenses cataloged for the 1.75-inch optical format. Use the camera dimensions, magnification and working distance to choose a field suitable for dimensional inspection.
Products
0.112x bi-telecentric lens, WD 338 mm, 1.75"
LS-TCL-1189
- Magnification 0.112x
- Mount M42, M58
- Sensor 1.75"
$8,345.00Quote
Ships in 3-4 weeks
0.134x bi-telecentric lens, WD 372 mm, 1.75"
LS-TCL-1191
- Magnification 0.134x
- Mount M42, M58
- Sensor 1.75"
$5,340.00Quote
Ships in 3-4 weeks
0.121x bi-telecentric lens, WD 410 mm, 1.75"
LS-TCL-1190
- Magnification 0.121x
- Mount F-mount
- Sensor 1.75"
$5,340.00Quote
Ships in 3-4 weeks
0.153x bi-telecentric lens, WD 330 mm, 1.75"
LS-TCL-1192
- Magnification 0.153x
- Mount F-mount
- Sensor 1.75"
$4,200.00
Ships in 3-4 weeks
0.171x bi-telecentric lens, WD 318 mm, 1.75"
LS-TCL-1193
- Magnification 0.171x
- Mount M42, M58
- Sensor 1.75"
$3,650.00
Ships in 3-4 weeks
0.193x bi-telecentric lens, WD 300 mm, 1.75"
LS-TCL-1194
- Magnification 0.193x
- Mount F-mount
- Sensor 1.75"
$3,520.00
Ships in 3-4 weeks
0.242x bi-telecentric lens, WD 273 mm, 1.75"
LS-TCL-1196
- Magnification 0.242x
- Mount F-mount
- Sensor 1.75"
$2,750.00
Ships in 3-4 weeks
0.213x bi-telecentric lens, WD 288 mm, 1.75"
LS-TCL-1195
- Magnification 0.213x
- Mount M42, M58
- Sensor 1.75"
$2,750.00
Ships in 3-4 weeks
0.806x bi-telecentric lens, WD 110 mm, 1.75"
LS-TCL-1207
- Magnification 0.806x
- Mount F-mount
- Sensor 1.75"
$1,705.00
Ships in 3-4 weeks
0.363x bi-telecentric lens, WD 228 mm, 1.75"
LS-TCL-1200
- Magnification 0.363x
- Mount F-mount
- Sensor 1.75"
$1,705.00
Ships in 3-4 weeks
0.29x bi-telecentric lens, WD 258 mm, 1.75"
LS-TCL-1198
- Magnification 0.29x
- Mount F-mount
- Sensor 1.75"
$1,340.00
Ships in 3-4 weeks
0.264x bi-telecentric lens, WD 263 mm, 1.75"
LS-TCL-1197
- Magnification 0.264x
- Mount M42, M58
- Sensor 1.75"
$1,340.00
Ships in 3-4 weeks
0.322x bi-telecentric lens, WD 208 mm, 1.75"
LS-TCL-1199
- Magnification 0.322x
- Mount F-mount
- Sensor 1.75"
$1,285.00
Ships in 3-4 weeks
0.518x bi-telecentric lens, WD 128 mm, 1.75"
LS-TCL-1203
- Magnification 0.518x
- Mount F-mount
- Sensor 1.75"
$740.00
Ships in 3-4 weeks
0.453x bi-telecentric lens, WD 158 mm, 1.75"
LS-TCL-1202
- Magnification 0.453x
- Mount F-mount
- Sensor 1.75"
$740.00
Ships in 3-4 weeks
0.403x bi-telecentric lens, WD 178 mm, 1.75"
LS-TCL-1201
- Magnification 0.403x
- Mount F-mount
- Sensor 1.75"
$740.00
Ships in 3-4 weeks
0.604x bi-telecentric lens, WD 128 mm, 1.75", F17.1
LS-TCL-1205
- Magnification 0.604x
- Mount F-mount
- Sensor 1.75"
$705.00
Ships in 3-4 weeks
0.604x bi-telecentric lens, WD 128 mm, 1.75", F11.3
LS-TCL-1204
- Magnification 0.604x
- Mount F-mount
- Sensor 1.75"
$705.00
Ships in 3-4 weeks
0.69x bi-telecentric lens, WD 118 mm, 1.75"
LS-TCL-1206
- Magnification 0.69x
- Mount F-mount
- Sensor 1.75"
$695.00
Ships in 3-4 weeks
1.115x bi-telecentric lens, WD 73 mm, 1.75"
LS-TCL-1208
- Magnification 1.115x
- Mount F-mount
- Sensor 1.75"
$590.00
Ships in 3-4 weeks
0.156× telecentric lens, APS-C, M42-mount
LS-TCL-0129
- Mount M42
- Sensor 1.75"
- Resolution 33 μm
$8,359.00Quote
Lead time confirmed with your quote
0.156× telecentric lens, APS-C, F-mount
LS-TCL-0128
- Mount F-mount
- Sensor 1.75"
- Resolution 33 μm
$8,359.00Quote
Lead time confirmed with your quote
0.184× telecentric lens, APS-C, M42-mount
LS-TCL-0127
- Mount M42
- Sensor 1.75"
- Resolution 28 μm
$6,959.00Quote
Lead time confirmed with your quote
| Compare | |||||||||
|---|---|---|---|---|---|---|---|---|---|
 LS-TCL-11880.097x bi-telecentric lens, WD 465 mm, 1.75"
| 0.097x | F-mount | 1.75" | 465±6 mm | F8.5 | dia. 300 mm | $8,800.00Quote | Ships in 3-4 weeks | |
 LS-TCL-11890.112x bi-telecentric lens, WD 338 mm, 1.75"
| 0.112x | M42, M58 | 1.75" | 338±5 mm | F6.8 | dia. 258 mm | $8,345.00Quote | Ships in 3-4 weeks | |
 LS-TCL-11910.134x bi-telecentric lens, WD 372 mm, 1.75"
| 0.134x | M42, M58 | 1.75" | 372±5 mm | F6.8 | dia. 216 mm | $5,340.00Quote | Ships in 3-4 weeks | |
 LS-TCL-11900.121x bi-telecentric lens, WD 410 mm, 1.75"
| 0.121x | F-mount | 1.75" | 410±6 mm | F6.8 | dia. 240 mm | $5,340.00Quote | Ships in 3-4 weeks | |
 LS-TCL-11920.153x bi-telecentric lens, WD 330 mm, 1.75"
| 0.153x | F-mount | 1.75" | 330±5 mm | F6.8 | dia. 190 mm | $4,200.00 | Ships in 3-4 weeks | |
 LS-TCL-11930.171x bi-telecentric lens, WD 318 mm, 1.75"
| 0.171x | M42, M58 | 1.75" | 318±5 mm | F6.8 | dia. 170 mm | $3,650.00 | Ships in 3-4 weeks | |
 LS-TCL-11940.193x bi-telecentric lens, WD 300 mm, 1.75"
| 0.193x | F-mount | 1.75" | 300±5 mm | F9.7 | dia. 150 mm | $3,520.00 | Ships in 3-4 weeks | |
 LS-TCL-11960.242x bi-telecentric lens, WD 273 mm, 1.75"
| 0.242x | F-mount | 1.75" | 273±5 mm | F6.8 | dia. 120 mm | $2,750.00 | Ships in 3-4 weeks | |
 LS-TCL-11950.213x bi-telecentric lens, WD 288 mm, 1.75"
| 0.213x | M42, M58 | 1.75" | 288±5 mm | F6.8 | dia. 136 mm | $2,750.00 | Ships in 3-4 weeks | |
 LS-TCL-12070.806x bi-telecentric lens, WD 110 mm, 1.75"
| 0.806x | F-mount | 1.75" | 110±2 mm | F13.5 | dia. 36 mm | $1,705.00 | Ships in 3-4 weeks | |
 LS-TCL-12000.363x bi-telecentric lens, WD 228 mm, 1.75"
| 0.363x | F-mount | 1.75" | 228±4 mm | F6.8 | dia. 80 mm | $1,705.00 | Ships in 3-4 weeks | |
 LS-TCL-11980.29x bi-telecentric lens, WD 258 mm, 1.75"
| 0.29x | F-mount | 1.75" | 258±4 mm | F6.8 | dia. 100 mm | $1,340.00 | Ships in 3-4 weeks | |
 LS-TCL-11970.264x bi-telecentric lens, WD 263 mm, 1.75"
| 0.264x | M42, M58 | 1.75" | 263±4 mm | F6.8 | dia. 110 mm | $1,340.00 | Ships in 3-4 weeks | |
 LS-TCL-11990.322x bi-telecentric lens, WD 208 mm, 1.75"
| 0.322x | F-mount | 1.75" | 208±3 mm | F8.5 | dia. 90 mm | $1,285.00 | Ships in 3-4 weeks | |
 LS-TCL-12030.518x bi-telecentric lens, WD 128 mm, 1.75"
| 0.518x | F-mount | 1.75" | 128±3 mm | F9.7 | dia. 56 mm | $740.00 | Ships in 3-4 weeks | |
 LS-TCL-12020.453x bi-telecentric lens, WD 158 mm, 1.75"
| 0.453x | F-mount | 1.75" | 158±3 mm | F8.5 | dia. 64 mm | $740.00 | Ships in 3-4 weeks | |
 LS-TCL-12010.403x bi-telecentric lens, WD 178 mm, 1.75"
| 0.403x | F-mount | 1.75" | 178±3 mm | F8.5 | dia. 72 mm | $740.00 | Ships in 3-4 weeks | |
 LS-TCL-12050.604x bi-telecentric lens, WD 128 mm, 1.75", F17.1
| 0.604x | F-mount | 1.75" | 128±3 mm | F17.1 | dia. 48 mm | $705.00 | Ships in 3-4 weeks | |
 LS-TCL-12040.604x bi-telecentric lens, WD 128 mm, 1.75", F11.3
| 0.604x | F-mount | 1.75" | 128±3 mm | F11.3 | dia. 48 mm | $705.00 | Ships in 3-4 weeks | |
 LS-TCL-12060.69x bi-telecentric lens, WD 118 mm, 1.75"
| 0.69x | F-mount | 1.75" | 118±3 mm | F11.4 | dia. 42 mm | $695.00 | Ships in 3-4 weeks | |
 LS-TCL-12081.115x bi-telecentric lens, WD 73 mm, 1.75"
| 1.115x | F-mount | 1.75" | 73±1 mm | F15.0 | dia. 26 mm | $590.00 | Ships in 3-4 weeks | |
 LS-TCL-01290.156× telecentric lens, APS-C, M42-mount
| - | M42 | 1.75" | - | - | - | $8,359.00Quote | Lead time confirmed with your quote | |
 LS-TCL-01280.156× telecentric lens, APS-C, F-mount
| - | F-mount | 1.75" | - | - | - | $8,359.00Quote | Lead time confirmed with your quote | |
 LS-TCL-01270.184× telecentric lens, APS-C, M42-mount
| - | M42 | 1.75" | - | - | - | $6,959.00Quote | Lead time confirmed with your quote |
Build a large-sensor measurement layout
A larger sensor can provide a useful measurement field, but only when the lens image circle and magnification suit the camera. Check the optical and mechanical constraints together. The field, working distance and lens body may have a greater effect on the layout than the format label alone.
- Use the camera active sensor dimensions and the model image-circle rating to confirm coverage; the optical-format designation is not a literal chip width.
- Calculate the object field from the active sensor and magnification, and compare it with the complete part envelope and required image detail.
- Review the lens mount, mass, body size and working distance before designing brackets or lighting. Confirm the printed distortion and telecentricity limits for the chosen model.
