Collimated lights · 6 models · from $379.00
Telecentric collimated light (TL series)
The Telecentric collimated light (TL series) is a range of 6 collimated lights from LumaSpec Vision, from $379.00. Every model below has its own page with full specifications, drawings and price.
Building a full system? Configure a camera, lens, light and controller that fit together →
The series at a glance
| Colour | Red, Green, Blue, White |
|---|---|
| Size | Under 50 mm, 50-100 mm, 100-200 mm |
| Voltage | 5 V |
| Type | Telecentric |
| Connector | 3-pin flat |
Features
- High uniform parallel light output
- Low distortion imaging
- Compact structure design
- Anti reflection interference
- Customization: three colour RGB light, dimensions (length/width/height), power cable length and interface, control mode (manual / remote / equipment linkage), installation (screw fixation / buckle installation)
- Outside diameter: dia. 150mm.
- Product shell made of aviation aluminum alloy material.
- Default 3PIN2 power interface, optional round head and 2PIN2 interface.
Typical uses
- Industrial and scientific fields with high requirements on imaging quality and measurement accuracy
- Use as telecentric back light opposite a telecentric lens
All 6 models in the Telecentric collimated light (TL series)
| Model | Size | Power | Colours | Price | Availability | Link |
|---|---|---|---|---|---|---|
| LS-TL40 | 3 W | $379.00 | 14 in stock | View | ||
| LS-TL60 | 3 W | $509.00 | 13 in stock | View | ||
| LS-TL80 | 3 W | $629.00 | 14 in stock | View | ||
| LS-TL100 | 3 W | $759.00 | 14 in stock | View | ||
| LS-TL100-L90 | 3 W | $759.00 | 14 in stock | View | ||
| LS-TL150 | 3 W | $1,079.00 | 16 in stock | View |
