Fixed code readers

Hikrobot MV-ID5120RM-08L-RBN Industrial Code Reader

Model MV-ID5120RM-08L-RBNHikrobot

Resolution4096 × 3024
InterfaceGigabit Ethernet (1000 Mbit/s)
Speed10 fps
Lens mountD14
Focal length8 mm

$1,969.00

Ships in 2-3 weeks

0.67 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineer Browse Fixed code readers

MV-ID5120RM-08L-RBN: resolution 4096 x 3024; max. frame rate 10 fps; focal length 8 mm; data interface Gigabit Ethernet (1000 Mbit/s); lens mount D14-mount, liquid lens focus supported.

Hikrobot MV-ID5120RM-08L-RBN Industrial Code Reader. Adopts a 12 MP high-performance rolling shutter sensor for high-speed image acquisition and high image quality. Adopts built-in deep learning algorithm to read codes with good robustness.

Tracked worldwide shippingTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CERoHSKC

Specifications

General

Model	MV-ID5120RM-08L-RBN
Brand	Hikrobot
Lens cap	Half-polarized lens cap by default. Transparent and fully-polarized caps are optional.
Indicator	Multi-directional device body indicator

Optics

Focal length	8 mm

Sensor and imaging

Symbologies	1D codes: Code 39, Code 93, Code 128 (GS1-128 included), CodaBar, EAN 8, EAN 13, UPCA, UPCE, ITF 14, ITF 25, Matrix 25, MSI, China Post, Code 11, Industrial 2of5, and Pharmacode; 2D codes: QR Code (GS1-QR included), Data Matrix (GS1-DM included), MicroQR, AZTEC, HanXin; Stacked codes: PDF417, MicroPDF417
Max. frame rate	10 fps
Max. reading speed	30 codes/sec
Sensor type	Rolling shutter, mono, 1/1.57", 2 μm × 2 μm
Resolution	4096 × 3024
Exposure time	33 μs to 1 sec
Gain	0 dB to 34 dB

Interfaces and I/O

Data interface	Gigabit Ethernet (1000 Mbit/s)
Communication protocol	SmartSDK, TCP Client, Serial, FTP, TCP Server, Profinet, MELSEC/SLMP, Ethernet/IP, ModBus, ModBus RTU, UDP, Fins
Digital I/O	12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 3/4/5) × 3, RS-232 input × 1, and RS-232 output × 1.; Supports device triggering via pressing button on device and smart tune.
Client software	IDMVS

Light

Light source	Red light by default. White/blue/IR light is optional.

Environment and compliance

Ingress protection	IP67 (under proper installation of waterproof lens cap)
Temperature	Working temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Vibration resistance	Device only: 10 Hz to 55 Hz, 1.5 mm full amplitude, 2 hours per axis (X/Y/Z) (IEC 60068-2-6:2007\GB/T 2423.10-2019)
Shock resistance	Device only, 30 g / 11 ms, half-sine wave, 500 shocks per axis (6 directions) (IEC 60068-2-27\GB/T 2423.5-2019)
Certification	CE, RoHS, KC

Electrical

Power supply	24 VDC
Power consumption	Avg.: 15.5 W @ 24 VDC (light source enabled); Max.: 36 W @ 24 VDC (light source enabled)

Mechanical

Lens mount	D14-mount, liquid lens focus supported
Dimension	Straight angle: 112.3 mm × 54 mm × 60.2 mm (4.4" × 2.1" × 2.4"); Right angle: 88.7 mm × 54 mm × 82.5 mm (3.5" × 2.1" × 3.2")
Shell material	Metal
Weight	Approx. 405 g (0.9 lb.)
Shipping weight (estimated)	0.67 kg

Downloads

Features

Frame rate up to 10 fps
Exposure time 33 µs to 1 s
Adopts a 12 MP high-performance rolling shutter sensor for high-speed image acquisition and high image quality.
Adopts built-in deep learning algorithm to read codes with good robustness.
Supports code score and quality evaluation for code printing.
Supports communication protocols including TCP, Serial, FTP, Profinet, Melsec/SLMP, Ethernet/IP, ModBus, ModBus RTU, UDP, and FINS.
Supports ingress protection IP67.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Engineering data

The MV-ID5120RM-08L-RBN at a glance

The numbers that set this model apart, taken from its own printed specifications.

Resolution4096 × 3024 px

Max. frame rate10 fps

Max. reading speed30 codes/s

Focal length8 mm

Ingress protectionIP67

Power consumption15.5 Wavg. at 24 V DC; max. 36 W
