Hikrobot MV-ID5200M 20MP Allfunction Industrial Code Reader

Model MV-ID5200MHikrobot

Resolution5440 × 3648
InterfaceGigabit Ethernet (1000 Mbit/s)
Speed20 fps
Lens mountC-mount

$1,969.00

Ships in 2-3 weeks

0.76 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-ID5200M 20MP Allfunction Industrial Code Reader. Adopts 20 MP rolling shutter sensor with high performance to provide high-quality images. Adopts built-in deep learning algorithm to read codes with good robustness.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-ID5200M
Brand	Hikrobot
Lens cap	Transparent lens cap
Indicator	Power indicator (PWR), network indicator (LNK/ACT), and user-defined indicator (U1/U2).

Sensor and imaging

Symbologies	1D codes: Code 39, Code 93, Code 128 (GS1-128 included), CodaBar, EAN 8, EAN 13, UPCA, UPCE, ITF 14, ITF 25, Matrix 25, MSI, China Post, Code 11, Industrial 2of5, and Pharmacode; 2D matrix codes: QR Code (GS1-QR included), Data Matrix (GS1-DM included), MicroQR, AZTEC, HanXin, MAXCODE; 2D stacked codes: PDF417, MicroPDF417
Max. frame rate	20 fps
Max. reading speed	36 codes/sec
Sensor type	CMOS, rolling shutter, mono, 1", 2.4 μm × 2.4 μm
Resolution	5440 × 3648
Exposure time	16 μs to 500 ms
Gain	0 dB to 40 dB

Interfaces and I/O

Data interface	Gigabit Ethernet (1000 Mbit/s)
Communication protocol	SmartSDK, TCP Client, Serial, FTP, TCP Server, Profinet, Ethernet/IP, Melsec/SLMP, Fins, ModBus, UDP, Fins, ModBus RTU
Digital I/O	12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 3/4/5) × 3, RS-232 input × 1, and RS-232 output × 1.
Client software	IDMVS

Light

Light source	No built-in light source

Environment and compliance

Ingress protection	IP67 (under proper installation of waterproof lens cap)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Vibration resistance	Device only: 10 Hz to 55 Hz, 1.5 mm full amplitude, 2 hours per axis (X/Y/Z) (IEC 60068-2-6:2007\GB/T 2423.10-2019)1
Shock resistance	Device only, 30 g/11 ms, half-sine wave, 500 shocks per axis (6 directions) (IEC 60068-2-27\GB/T 2423.5-2019)1
Certification	CE, RoHS, KC

Electrical

Power supply	12 VDC to 24 VDC
Power consumption	Avg.: 9 W @ 24 VDC; Max.: 12 W @ 24 VDC

Mechanical

Lens mount	C-mount
Shell material	Metal
Dimension	109.5 mm × 64.4 mm × 109 mm (4.3" × 2.5" × 4.3")
Weight	Approx. 470 g (1.0 lb.)
Shipping weight (estimated)	0.76 kg

Downloads

Features

Adopts 20 MP rolling shutter sensor with high performance to provide high-quality images.
Adopts built-in deep learning algorithm to read codes with good robustness.
Supports multiple communication protocols, including UDP, TCP/IP, Serial, FTP, Profinet, Ethernet/IP, MELSEC, Modbus, Modbus RTU, and Fins.
Supports drawing ROI via chessboard, and supports 1D codes, 2D codes, and stacked codes.
Ingress protection rating 67.
