Hikrobot MV-CS040-A0UM 4MP Area Scan Camera, USB3.0, 2nd Gen, Mono.

Model MV-CS040-A0UMHikrobot

Resolution2048 × 2048
SensorCMOS, global shutter
InterfaceUSB 3.0, compatible with USB 2.0
Speed90.1 fps @ 2048 × 2048 Mono 8
Lens mountC-mount
Mono / colourMono

$1,359.00

Ships in 2-3 weeks

0.22 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CS040-A0UM 4MP Area Scan Camera, USB3.0, 2nd Gen, Mono.. Adopts global shutter CMOS sensor providing high signal-to-noise ratio, wide dynamic range and high quality images. Resolution of 2048 × 2048, pixel size of 5.5 μm × 5.5 μm.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CS040-A0UM
Brand	Hikrobot
Compatibility	USB3 Vision, GenlCam

Sensor and imaging

Sensor type	CMOS, global shutter
Pixel size	5.5 μm × 5.5 μm
Sensor size	1"
Resolution	2048 × 2048
Max. frame rate	90.1 fps @ 2048 × 2048 Mono 8
Dynamic range	59.7 dB
SNR	39.6 dB
Gain	0 dB to 12 dB
Exposure time	30 μs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono/color	Mono
Pixel format	Mono 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2, 4 × 4
Decimation	Supports 1 × 1, 2 × 2, 4 × 4
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	USB 3.0, compatible with USB 2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS or third-party software meeting with USB3 Vision Protocol

Environment and compliance

Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux

Electrical

Power supply	9 VDC to 24 VDC, supports USB 3.0 power supply
Power consumption	Typ. 2.4 W @ 5 VDC (USB 3.0 provides power supply)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 88 g (0.2 lb.)
Shipping weight (estimated)	0.22 kg

Downloads

Features

Adopts global shutter CMOS sensor providing high signal-to-noise ratio, wide dynamic range and high quality images.
Resolution of 2048 × 2048, pixel size of 5.5 μm × 5.5 μm.
Supports hardware trigger, software trigger, and free run.
Compact design with mounting holes on panels for flexible mounting from 4 sides.
Compatible with USB3 Vision Protocol, GenlCam Standard, and the third-party software based on the protocol and standard.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer
