Hikrobot MV-CS028-10UM 2.8MP Area Scan Camera, USB3.0, IMX421, 2nd Gen., Mono

Model MV-CS028-10UMHikrobot

Resolution1936 × 1464
SensorCMOS, global shutter
InterfaceUSB3.0, compatible with USB2.0
Speed132.2 fps @ 1936 × 1464
Lens mountC-mount
Mono / colourMono

$859.00

Ships in 2-3 weeks

0.21 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CS028-10UM 2.8MP Area Scan Camera, USB3.0, IMX421, 2nd Gen., Mono. Adopts brand new design to reduce power consumption. Supports auto or manual adjustment of gain, exposure time, LUT, Gamma correction, contrast ratio, etc.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CS028-10UM
Brand	Hikrobot
Compatibility	USB3 Vision, GenlCam

Sensor and imaging

Sensor type	CMOS, global shutter
Sensor model	Sony® IMX421
Pixel size	4.5 μm × 4.5 μm
Sensor size	2/3"
Resolution	1936 × 1464
Max. frame rate	132.2 fps @ 1936 × 1464
Dynamic range	71.1 dB
SNR	43.6 dB
Gain	0 dB to 24 dB
Exposure time	UltraShort exposure mode: 1 μs to 5 μs; Standard exposure mode: 9 μs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode
Pixel format	Mono 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2
Decimation	Supports 1 × 1, 2 × 2
Reverse image	Supports horizontal and vertical reverse image output
Mono/color	Mono

Interfaces and I/O

Data interface	USB3.0, compatible with USB2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS or third-party software meeting with USB3.0 Vision Protocol

Environment and compliance

Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows 7/10, 32/64-bit Linux

Electrical

Power supply	9 VDC to 24 VDC, supports USB3.0 power supply
Power consumption	Typ. 2.8 W @ 5 VDC (USB3.0 provides power supply)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 80 g (0.18 lb.)
Shipping weight (estimated)	0.21 kg

Downloads

Features

Adopts brand new design to reduce power consumption.
Supports auto or manual adjustment of gain, exposure time, LUT, Gamma correction, contrast ratio, etc.
Compact design with mounting holes on panels for flexible mounting from 4 sides.
Compatible with USB3 Vision Protocol, GenlCam Standard, and the third-party software based on the protocol and standard.
