Hikrobot MV-CS020-10UC 2MP Area Scan Camera, USB3.0, IMX430, 2nd Generation, Color

Model MV-CS020-10UCHikrobot

Resolution1624 × 1240
SensorCMOS, global shutter
InterfaceUSB 3.0, compatible with USB 2.0
Speed90 fps @ 1624 × 1240 Bayer RG 8
Lens mountC-mount
Mono / colourColor

$629.00

Ships in 2-3 weeks

0.21 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CS020-10UC 2MP Area Scan Camera, USB3.0, IMX430, 2nd Generation, Color. Adopts brand new design to reduce power consumption. Supports sequencer, passive transmission, etc.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CS020-10UC
Brand	Hikrobot
Compatibility	USB3 Vision, GenlCam

Sensor and imaging

Sensor type	CMOS, global shutter
Sensor model	Sony® IMX430
Pixel size	4.5 μm × 4.5 μm
Sensor size	1/1.7"
Resolution	1624 × 1240
Max. frame rate	90 fps @ 1624 × 1240 Bayer RG 8
Dynamic range	71.5 dB
SNR	43.7 dB
Gain	0 dB to 24 dB
Exposure time	UltraShort exposure mode: 1 μs to 5 μs; Standard exposure mode: 6 μs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono/color	Color
Pixel format	Mono 8/10/12; Bayer RG 8/10/10Packed/12/12Packed; YUV422Packed, YUV422_YUYV_Packed; RGB 8, BGR 8
Binning	Supports 1 × 1, 2 × 2
Decimation	Supports 1 × 1, 2 × 2
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	USB 3.0, compatible with USB 2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS or third-party software meeting with USB 3.0 Vision Protocol

Environment and compliance

Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows 7/10, 64-bit Window 11, and 32/64-bit Linux

Electrical

Power supply	9 VDC to 24 VDC, supports USB power supply
Power consumption	Typ. 2.4 W @ 5 VDC (USB 3.0 provides power supply)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 80 g (0.18 lb.)
Shipping weight (estimated)	0.21 kg

Downloads

Features

Adopts brand new design to reduce power consumption.
Supports sequencer, passive transmission, etc.
Color camera supports white balance, CCM, Super Palette, Super Bayer, etc.
Supports hard trigger, software trigger, free run, etc.
Compatible with USB3 Vision Protocol, GenlCam Standard, and the third-party software based on the protocol and standard.
