  • LS-MBL-0129 dimensions (mm)

M12 board lenses

14 mm, 1/1.7", 12 MP, M12-mount Low-Distortion M12 Lens, dia. 14 x 14.86mm (LS-MBL-0143)

Model LS-MBL-0143

  • Focal length14mm
  • MountM12
  • Sensor1/1.7"
  • ApertureF2.8 Fixed iris
  • Resolution12 Megapixel
$109.00

Ships in 2-3 weeks

0.11 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

14 mm, 1/1.7", 12 MP, M12-mount Low-Distortion M12 Lens, dia. 14 x 14.86mm (LS-MBL-0143)LS-MBL-0143

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

14 mm, 1/1.7", 12 MP, M12-mount Low-Distortion M12 Lens. A 14 mm F2.8 fixed-iris M12 S-mount lens for 1/1.7" 12-megapixel sensors, for recognition, scanners and machine vision. At a glance: focal length 14mm; format 1/1.7"; resolution 12 Megapixel; aperture F2.8 Fixed iris; mount M12.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-MBL-0143
Format1/1.7"
CRA<8.2°

Optics

Focal length14mm
Image circledia. 9.2
ApertureF2.8 Fixed iris
Relative illumination80%
Distortion-1.48%
Field of view (dia. 9.2 FOV)196 x 160 x 119 @300mm W.D; 326 x 266 x 199 @ 500m W.D
Max image circledia. 9.2
Field of view (dia. 9.2)196 x 1608119 @ 300 mm W.D (as printed); 326 x 266 x 199 @ 500m W.D

Sensor and imaging

Resolution12 Megapixel
Pixel size1.85μm

Mechanical

Sizedia. 14 x 14.86mm
MountM12
Weight8g
Optical total length20.53 mm
Shipping weight (estimated)0.11 kg
