Coaxial Light, 50 x 50 mm, White (LS-CXL-0229)
  • Coaxial Light, 50 x 50 mm, White (LS-CXL-0229)
  • LS-CXL-0229 dimensions (mm)

Coaxial lights

Coaxial Light, 50 x 50 mm, White (LS-CXL-0229)

Model LS-CXL-0229

  • ColourWhite
  • Emitting area50 mm × 50 mm
  • Size79 mm × 59.7 mm × 56 mm
  • Power5.5 W
$219.00

Ships in 2-3 weeks

0.45 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Coaxial Light, 50 x 50 mm, White (LS-CXL-0229)LS-CXL-0229

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-CXL-0229: emitting area dimension 50 mm x 50 mm, dimension 79 mm x 59.7 mm x 56 mm, power 5.5 W, color White.

Coaxial Light, 50 x 50 mm, White. Features special beam splitter design and improved light efficiency. Features efficient heat dissipation and extended service life.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-CXL-0229
Safety classNo danger

Interfaces and I/O

Connector typeSMR-03V-B
Cable length1 m

Light

ColorWhite
Center illuminance/irradiance≥ 35000 lux
Color temperature6000K to 7000K
Emitting area dimension50 mm × 50 mm
Diffuse plate includedIncluded

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Humidity20% RH to 90% RH (no condensation)

Electrical

Power5.5 W
Supply voltage (derived)24 V DC, derived: all 370 lights of this range with the same connector type that state a voltage are rated 24 V

Mechanical

Dimension79 mm × 59.7 mm × 56 mm
Weight250 g
Shipping weight (estimated)0.45 kg

Engineering data

Drive and fit the LS-CXL-0229

Worked out from the printed voltage, power and dimensions: what the light draws and what it needs from a controller.

Supply24 V DC
Current at 24 V229 mACalculated: printed power ÷ supply voltage
Controller channel it needs24 V constant voltage, at least 5.5 W
Emitting area50 × 50 mmKeep the camera's field of view inside it for an even background.
Operating temperature0 to 40 °C
Cable length1 m
Center illuminance≥ 35000 lux

Mounting and installation

Cable1 mSMR-03V-B connector

As printed in this model's specifications and dimension drawing. Check the drawing in Downloads before you drill a fixture.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Controllers for this light

10 W per channel at 24 V for this 5.5 W light

8.1 W per channel at 24 V for this 5.5 W light

7.5 W per channel at 24 V for this 5.5 W light

20 W per channel at 24 V for this 5.5 W light

15 W per channel at 24 V for this 5.5 W light

24 W per channel at 24 V for this 5.5 W light

Light cables

Other models in the Coaxial lights (LS-CXL-S34) series

See all 14 models
ModelEmitting areaSizePowerPriceAvailabilityLink
LS-CXL-0229This model50 mm × 50 mm79 mm × 59.7 mm × 56 mm5.5 W$219.00 Ships in 2-3 weeks
LS-CXL-022332.5 mm × 32 mm69 mm × 37.9 mm × 38 mm3.3 W$159.00 Ships in 2-3 weeks View
LS-CXL-022132.5 mm × 32 mm69 mm × 37.9 mm × 38 mm3.6 W$159.00 Ships in 2-3 weeks View
LS-CXL-022232.5 mm × 32 mm69 mm × 37.9 mm × 38 mm2.2 W$159.00 Ships in 2-3 weeks View
LS-CXL-022640 mm × 40 mm69 mm × 45.7 mm × 46 mm5.4 W$179.00 Ships in 2-3 weeks View
LS-CXL-022440 mm × 40 mm69 mm × 45.7 mm × 46 mm5.9 W$179.00 Ships in 2-3 weeks View
LS-CXL-022540 mm × 40 mm69 mm × 45.7 mm × 46 mm4.1 W$179.00 Ships in 2-3 weeks View
LS-CXL-022750 mm × 50 mm79 mm × 59.7 mm × 56 mm7 W$219.00 Ships in 2-3 weeks View
LS-CXL-022850 mm × 50 mm79 mm × 59.7 mm × 56 mm4.7 W$219.00 Ships in 2-3 weeks View
LS-CXL-023260 mm × 60 mm89 mm × 67.3 mm × 66 mm9.6 W$269.00 Ships in 2-3 weeks View
LS-CXL-023060 mm × 60 mm89 mm × 67.3 mm × 66 mm8.7 W$269.00 Ships in 2-3 weeks View
LS-CXL-023160 mm × 60 mm89 mm × 67.3 mm × 66 mm6.7 W$269.00 Ships in 2-3 weeks View
LS-CXL-023470 mm × 70 mm99 mm × 77.7 mm × 76 mm10.8 W$309.00 Ships in 2-3 weeks View
LS-CXL-023370 mm × 70 mm99 mm × 77.7 mm × 76 mm12.6 W$309.00 Ships in 2-3 weeks View
