Machine vision lenses

FA lens series, 16 mm, 2/3", C-Mount, FOV 30.3° (LS-FFL-1578)

Model LS-FFL-1578

Focal length16mm
MountC-mount
Sensor2/3"
Aperture1:1.4~16
Resolution5MP
Field of view30.3°

$209.00

Ships in 2-3 weeks

0.38 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

FA lens series: compact design, adjustable aperture, ultra-high resolution and minimized distortion; supports 1/1.8", 1/1.7", 2/3", 1" sensors, max sensor 1.1".

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	LS-FFL-1578
Angle H (2/3")	30.3°
Angle H (1/2")	22.3°
Angle H (1/3")	16.8°
Angle V (2/3")	23°
Angle V (1/2")	16.8°
Angle V (1/3")	12.6°
Angle D (2/3")	37.3°
Angle D (1/2")	27.8°
Angle D (1/3")	20.9°
Flange back	17.526mm in air
Front/Rear Effective Dia	Front dia. 19mm Rear dia. 14.2mm
F.NO	1:1.4~16

Optics

Object Dimension at M.O.D H (2/3")	170.4mm
Object Dimension at M.O.D H (1/2")	123.7mm
Object Dimension at M.O.D H (1/3")	116mm
Object Dimension at M.O.D V (2/3")	127.6mm
Object Dimension at M.O.D V (1/2")	92.7mm
Object Dimension at M.O.D V (1/3")	69.4mm
Object Dimension at M.O.D D (2/3")	212.8mm
Object Dimension at M.O.D D (1/2")	154.9mm
Object Dimension at M.O.D D (1/3")	123.7mm
Focus distance(min)	0.3M
Back focus	12.7mm in air
Filter screw size	M30.5x0.5
Focal length	16mm
Field of view H	30.3°
Field of view V	23°
Field of view D	37.3°
Distortion	<0.1%
Aperture	1:1.4~16

Sensor and imaging

Sensor	2/3"
Resolution	5MP
Sensor format	2/3"

Environment and compliance

Temperature range	-10~+50°C
Storage temperature range	-20~+60°C

Mechanical

Mount	C-Mount
Max Diameter(RATIO)	F=1:1.4~16
Picture size	2/3" / 1/2" / 1/3"
Shipping weight	0.38 kg
