6-15 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens (LS-CTV-0135)
  • 6-15 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens (LS-CTV-0135)
  • LS-CTV-0135 dimensions (mm)

CCTV lenses

6-15 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens (LS-CTV-0135)

Model LS-CTV-0135

  • Focal length6-15 mm
  • MountC-mount
  • Sensor2/3"
  • ApertureF1.4 DC (Auto Iris)
  • Resolution3 MP
$79.00

Ships in 2-3 weeks

0.39 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

6-15 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens (LS-CTV-0135)LS-CTV-0135

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

6-15 mm, 2/3", 3 MP, C-mount Varifocal CCTV Lens. 6-15 mm, 2/3" large-format 3 MP varifocal lens with F1.4 DC auto iris and IR correction. Covers 2/3", 1/1.8" and 1/2" cameras for surveillance, smart city and ITS. At a glance: focal length 6-15 mm; format 2/3"; resolution 3 MP; aperture F1.4 DC (Auto Iris); mount C.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-CTV-0135
IR correctionIR
Format2/3"
Notes-20 ~ +80°
Angle of view (2/3" (16:9), DxHxV)100 x 86 x 46 deg
Angle of view (2/3" (4:3), DxHxV)100 x 77 x 58 deg
Angle of view (2/3" (16:9))100 x 86 x 46 deg
Angle of view (2/3" (4:3))100 x 77 x 58 deg
T.T.L.65.24 mm

Optics

Focal length6-15 mm
ApertureF1.4 DC (Auto Iris)
M.O.D.0.3 m
Distortion-32.1% ~ -3.9%
TTL65.24 mm

Sensor and imaging

Resolution3 MP

Mechanical

Sizedia. 43.4 x 47.71 mm
MountC
Weight210 g
Shipping weight (estimated)0.39 kg
