Ring lights
IR light, LS-RNG-S43 series
- 8 models
- from $109.00
- Series LS-RNG-S43
The IR light, LS-RNG-S43 series is a range of 8 ring lights from LumaSpec Vision, from $109.00. It comes in 7 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 6 mm, 62.4 mm, 65 mm, 75.4 mm, 81 mm, 82 mm, 109.8 mm
- Type
- Standard
- Voltage
- 24 V
Features
- Custom made for light shape and illumination mode
- Using the difference in spectral reflectance for a variety of measurements
Typical uses
- LCD screen inspection
- Character reading
- Screen alignment
- Edge extraction
- Surface pattern appearance
- Foreign matter inspection through liquid
All 8 models in the IR light, LS-RNG-S43 series
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-RNG-0348 | 6 mm | 1.8 | 6 | OD24 x ID8 x H59 | $109.00 | View |
| LS-RNG-0341 | 65 mm | 5.9 | 65 | OD73 x ID36 x H17.5 | $219.00 | View |
| LS-RNG-0343 | 65 mm | 6.9 | 65 | OD74 x ID35 x H20 | $219.00 | View |
| LS-RNG-0345 | 81 mm | 11 | 81 | OD90 x ID50 x H18 | $249.00 | View |
| LS-RNG-0346 | 75.4 mm | 14 | 75.4 | OD90 x ID50 x H21 | $249.00 | View |
| LS-RNG-0342 | 62.4 mm | 4.9 | 62.4 | OD74 x ID40 x H20 | $269.00 | View |
| LS-RNG-0344 | 82 mm | 12 | 82 | OD90 x ID44 x H20 | $279.00 | View |
| LS-RNG-0347 | 109.8 mm | 17 | 109.8 | OD120 x ID65 x H22 | $319.00 | View |
