Line scan lenses
Line scan lens (LS-LSL-S12)
- 12 models
- from $2,819.00
- Series LS-LSL-S12
The Line scan lens (LS-LSL-S12) is a range of 12 line scan lenses from LumaSpec Vision, from $2,819.00. It comes in 8 sizes or versions. Every model below has its own page with full specifications, drawings and price.
The series at a glance
- Sizes / versions
- 25 mm, M42-mount, 35 mm, M42/M58-mount, 35 mm, V-mount, 40 mm, M58/M72-mount, 40 mm, M72-mount, 50 mm, M42/M58/M72-mount, 60 mm, M42/M58/M72-mount, 80 mm
- Mount
- M42, M58, M72, V-mount
- Image circle
- 28 mm, 30 mm, 46.4 mm, 60 mm, 80 mm
- Focal length
- 25-50 mm, 50-100 mm
- Sensor format
- 4/3" - APS-C, Medium / large
Features
- Focal length 35mm.
- Large image plane:Image circle 28mm.
- High resolution, Low magnification, Excellent imaging effect.
- Anti-shock focusing fastening method.
All 12 models in the Line scan lens (LS-LSL-S12)
| Link | ||||||
|---|---|---|---|---|---|---|
| LS-LSL-0140 | 25 mm, M42-mount | 4K7μ | 25mm | 0.015x~0.05x | $2,819.00 | View |
| LS-LSL-0141 | 25 mm, M42-mount | 4K7μ | 25mm | 0.125x~0.175x | $2,819.00 | View |
| LS-LSL-0142 | 25 mm, M42-mount | 4K7μ | 25mm | 0.05x~0.125x | $2,819.00 | View |
| LS-LSL-0149 | 35 mm, V-mount | 2K10μ/4K7μ | 35mm | $2,859.00 | View | |
| LS-LSL-0143 | 35 mm, M42/M58-mount | 4K7μ | 35mm | 0.01x~0.5x | $2,859.00 | View |
| LS-LSL-0144 | 40 mm, M72-mount | 8K7μ | 40mm | 0.04x-0.25x | $2,879.00 | View |
| LS-LSL-0150 | 40 mm, M58/M72-mount | 16K3.45μ | 40mm | 0.004x~0.227x | $2,879.00 | View |
| LS-LSL-0145 | 50 mm, M42/M58/M72-mount | 8K7μ | 50mm | 0.025x~0.07x | $2,929.00 | View |
| LS-LSL-0146 | 50 mm, M42/M58/M72-mount | 8K7μ | 50mm | 0.07x~0.13x | $2,929.00 | View |
| LS-LSL-0147 | 50 mm, M42/M58/M72-mount | 8K7μ | 50mm | 0.15x~0.25x | $2,929.00 | View |
| LS-LSL-0148 | 60 mm, M42/M58/M72-mount | 8K7μ | 60mm | 0.05x~0.15x | $2,969.00 | View |
| LS-LSL-0151 | 80 mm | 16K5μ | 80mm | 0.04x~0.33x | $3,059.00 | View |
