Machine vision lenses
40mm, F2.8, Image Size φ37mm, Recommended Magnification 0.04~0.22X, M42-Mount (LS-AF4028M-M42)
Model LS-AF4028M-M42
40mm, F2.8, Image Size φ37mm, Recommended Magnification 0.04~0.22X, M42-Mount. Provides excellent consistency of image clarity. Provides large aperture, low distortion, low chromatic aberration, and high relative illumination.
Features
- Provides excellent consistency of image clarity.
- Provides large aperture, low distortion, low chromatic aberration, and high relative illumination.
- Provides max. image size Φ37 mm for APS-C area scan and 4k line scan cameras.
Specifications
| Model | LS-AF4028M-M42 |
|---|---|
| Focal length | 40 mm |
| F-number | F2.8 to F22 |
| Image size | Φ37 mm |
| Optical distortion | 0.62% |
| Magnification range | 0.22 x to 0.04 x |
| Working distance range | 200 mm to 1051 mm |
| Iris control | Manual |
| Focus control | Manual |
| Filter thread | M37 × 0.75 |
| Mount | M42 × P1 |
| Flange back length | 12 mm |
| Dimension | Φ47.6 mm × 50.5 mm to 62.7 mm (Φ1.9" × 2.0" to 2.5") |
| Weight | 171 g (0.4 Ib.) |
| Temperature | –10 °C to 50 °C (14 °F to 122 °F) |
| Certification | RoHS 2.0 |
| Shipping weight (estimated) | 0.34 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guideOther sizes in the AF series lenses series
