Ultraviolet light, 74 x 50 x 50 mm
LS-CXL-0257
- Colour UV
- Size L74xW50xH50(mm)
- Voltage 24 V
$329.00
Ships in 2-3 weeks
Lights
Coaxial lights
Coaxial lights send light down the camera's own axis through a beam splitter, so flat mirror-like surfaces - wafers, polished metal, printed foil, labels under film - image evenly without glare or hot spots.
Shop by colour: Red coaxial lights · Blue coaxial lights · Green coaxial lights · White coaxial lights · Infrared coaxial lights · UV coaxial lights
Products
Ultraviolet light, 84 x 60 x 60 mm
LS-CXL-0258
- Colour UV
- Size L84xW60xH60(mm)
- Voltage 24 V
$389.00
Ships in 2-3 weeks
60 x 61 mm Corner coaxial light
LS-CXL-0144
- Colour Red, Green, Blue, White
- Voltage 24 V
- Cable length 500 mm (drawings)
$269.00
Ships in 2-3 weeks
300 x 60 mm High brightness coaxial light
LS-CXL-0205
- Colour Red, Green, Blue, White
- Wavelength red 620-630 nm
- Wavelength green 520-530 nm
$2,269.00
Ships in 2-3 weeks
30 x 30 mm High-definition coaxial light
LS-CXL-0139
- Colour Red, Green, Blue, White
- Voltage 24 V
- Wavelength red 620-630 nm
$149.00
Ships in 2-3 weeks
39 x 38 mm High-definition coaxial light
LS-CXL-0140
- Colour Red, Green, Blue, White
- Voltage 24 V
- Wavelength red 620-630 nm
$179.00
Ships in 2-3 weeks
120 x 121 mm High brightness coaxial light
LS-CXL-0204
- Colour Red, Green, Blue, White
- Wavelength red 620-630 nm
- Wavelength green 520-530 nm
$609.00
Ships in 2-3 weeks
490 x 59 mm Coaxial light
LS-CXL-0135
- Colour Green, Blue, White
- Emitting area 490 x 65 mm
- Voltage 12 V
$5,259.00
Ships in 2-3 weeks
140 x 140 mm Coaxial light, 192 x 150 x 146 mm
LS-CXL-0131
- Colour White
- Wavelength red 620-630 nm
- Wavelength green 520-530 nm
$739.00
Ships in 2-3 weeks
19 x 19 mm High-definition coaxial light
LS-CXL-0138
- Colour Red, Green, Blue, White
- Voltage 24 V
- Wavelength red 620-630 nm
$119.00
Ships in 2-3 weeks
Collimated coaxial light
LS-CXL-0115
- Colour White
- Emitting area 100 x 100 mm
- Size L194xW110xH106(mm)
$1,139.00
Ships in 2-3 weeks
16 x 14.6 mm High-definition coaxial light
LS-CXL-0137
- Colour Red, Green, Blue, White
- Voltage 24 V
- Wavelength red 620-630 nm
$109.00
Ships in 2-3 weeks
Right-angle coaxial light, 94 x 70 x 70 mm
LS-CXL-0046
- Colour Red, Blue, Green, White
- Size L94xW70xH70(mm)
- Voltage 24V
$439.00
Ships in 2-3 weeks
Right-angle coaxial light, 114 x 92 x 92 mm
LS-CXL-0047
- Colour Red, Blue, Green, White
- Emitting area 80 x 70 mm
- Size L114xW92xH92(mm)
$559.00
Ships in 2-3 weeks
Right-angle coaxial light, 134 x 112 x 112 mm
LS-CXL-0048
- Colour Red, Blue, Green, White
- Emitting area 100 x 76 mm
- Size L134xW112xH112(mm)
$689.00
Ships in 2-3 weeks
Right-angle coaxial light, 64 x 40 x 40 mm
LS-CXL-0043
- Colour Red, Blue, Green, White
- Emitting area 30 x 20 mm
- Size L64xW40xH40(mm)
$279.00
Ships in 2-3 weeks
Right-angle coaxial light, 84 x 60 x 60 mm
LS-CXL-0045
- Colour Red, Blue, Green, White
- Emitting area 50 x 38 mm
- Size L84xW60xH60(mm)
$389.00
Ships in 2-3 weeks
Right-angle coaxial light, 74 x 50 x 50 mm
LS-CXL-0044
- Colour Red, Blue, Green, White
- Emitting area 40 x 33 mm
- Size L74xW50xH50(mm)
$329.00
Ships in 2-3 weeks
Right-angle coaxial light, 54 x 30 x 30 mm
LS-CXL-0042
- Colour Red, Blue, Green, White
- Emitting area 20 x 16 mm
- Size L54xW30xH30(mm)
$239.00
Ships in 2-3 weeks
High precision coaxial light, 94 x 70 x 70 mm
LS-CXL-0038
- Colour Red, Blue, Green, White
- Size L94xW70xH70(mm)
- Voltage 24V
$439.00
Ships in 2-3 weeks
High precision coaxial light, 154 x 130 x 132 mm
LS-CXL-0041
- Colour Red, Blue, Green, White
- Size L154xW130xH132(mm)
- Voltage 24V
$829.00
Ships in 2-3 weeks
High precision coaxial light, 134 x 110 x 112 mm
LS-CXL-0040
- Colour Red, Blue, Green, White
- Size L134xW110xH112(mm)
- Voltage 24V
$689.00
Ships in 2-3 weeks
High precision coaxial light, 84 x 60 x 60 mm
LS-CXL-0037
- Colour Red, Blue, Green, White
- Size L84xW60xH60(mm)
- Voltage 24V
$389.00
Ships in 2-3 weeks
High precision coaxial light, 74 x 50 x 50 mm
LS-CXL-0036
- Colour Red, Blue, Green, White
- Size L74xW50xH50(mm)
- Voltage 24V
$329.00
Ships in 2-3 weeks
| Compare | |||||||||
|---|---|---|---|---|---|---|---|---|---|
 LS-CXL-0257Ultraviolet light, 74 x 50 x 50 mm
| UV | L74xW50xH50(mm) | 24 V | 1.7W | UV: 365-405 nm | - | $329.00 | Ships in 2-3 weeks | |
|
LS-CXL-0258Ultraviolet light, 84 x 60 x 60 mm
| UV | L84xW60xH60(mm) | 24 V | 3.6W | UV: 365-405 nm | - | $389.00 | Ships in 2-3 weeks | |
 LS-CXL-014460 x 61 mm Corner coaxial light
| Red, Green, Blue, White | - | 24 V | - | - | 500 mm (drawings) | $269.00 | Ships in 2-3 weeks | |
 LS-CXL-0205300 x 60 mm High brightness coaxial light
| Red, Green, Blue, White | - | - | - | - | - | $2,269.00 | Ships in 2-3 weeks | |
 LS-CXL-013930 x 30 mm High-definition coaxial light
| Red, Green, Blue, White | - | 24 V | - | - | - | $149.00 | Ships in 2-3 weeks | |
|
LS-CXL-014039 x 38 mm High-definition coaxial light
| Red, Green, Blue, White | - | 24 V | - | - | - | $179.00 | Ships in 2-3 weeks | |
|
LS-CXL-0204120 x 121 mm High brightness coaxial light
| Red, Green, Blue, White | - | - | - | - | - | $609.00 | Ships in 2-3 weeks | |
 LS-CXL-0135490 x 59 mm Coaxial light
| Green, Blue, White | - | 12 V | 34W | - | - | $5,259.00 | Ships in 2-3 weeks | |
|
LS-CXL-0131140 x 140 mm Coaxial light, 192 x 150 x 146 mm
| White | - | - | - | - | - | $739.00 | Ships in 2-3 weeks | |
|
LS-CXL-013819 x 19 mm High-definition coaxial light
| Red, Green, Blue, White | - | 24 V | - | - | - | $119.00 | Ships in 2-3 weeks | |
 LS-CXL-0115Collimated coaxial light
| White | L194xW110xH106(mm) | - | 6W | - | - | $1,139.00 | Ships in 2-3 weeks | |
|
LS-CXL-013716 x 14.6 mm High-definition coaxial light
| Red, Green, Blue, White | - | 24 V | - | - | - | $109.00 | Ships in 2-3 weeks | |
 LS-CXL-0046Right-angle coaxial light, 94 x 70 x 70 mm
| Red, Blue, Green, White | L94xW70xH70(mm) | 24V | 8.7W/10.8W | - | - | $439.00 | Ships in 2-3 weeks | |
|
LS-CXL-0047Right-angle coaxial light, 114 x 92 x 92 mm
| Red, Blue, Green, White | L114xW92xH92(mm) | 24V | 15.2W/21.6W | - | - | $559.00 | Ships in 2-3 weeks | |
|
LS-CXL-0048Right-angle coaxial light, 134 x 112 x 112 mm
| Red, Blue, Green, White | L134xW112xH112(mm) | 24V | 26.0W/32.4W | - | - | $689.00 | Ships in 2-3 weeks | |
|
LS-CXL-0043Right-angle coaxial light, 64 x 40 x 40 mm
| Red, Blue, Green, White | L64xW40xH40(mm) | 24V | 2.9W/4.4W | - | - | $279.00 | Ships in 2-3 weeks | |
|
LS-CXL-0045Right-angle coaxial light, 84 x 60 x 60 mm
| Red, Blue, Green, White | L84xW60xH60(mm) | 24V | 6.5W/7.2W | - | - | $389.00 | Ships in 2-3 weeks | |
|
LS-CXL-0044Right-angle coaxial light, 74 x 50 x 50 mm
| Red, Blue, Green, White | L74xW50xH50(mm) | 24V | 4.4W/4.4W | - | - | $329.00 | Ships in 2-3 weeks | |
|
LS-CXL-0042Right-angle coaxial light, 54 x 30 x 30 mm
| Red, Blue, Green, White | L54xW30xH30(mm) | 24V | 1.5W/1.5W | - | - | $239.00 | Ships in 2-3 weeks | |
 LS-CXL-0038High precision coaxial light, 94 x 70 x 70 mm
| Red, Blue, Green, White | L94xW70xH70(mm) | 24V | 8.7W/10.8W | - | - | $439.00 | Ships in 2-3 weeks | |
|
LS-CXL-0041High precision coaxial light, 154 x 130 x 132 mm
| Red, Blue, Green, White | L154xW130xH132(mm) | 24V | 34.6W/45.4W | - | - | $829.00 | Ships in 2-3 weeks | |
|
LS-CXL-0040High precision coaxial light, 134 x 110 x 112 mm
| Red, Blue, Green, White | L134xW110xH112(mm) | 24V | 24.5W/32.4W | - | - | $689.00 | Ships in 2-3 weeks | |
|
LS-CXL-0037High precision coaxial light, 84 x 60 x 60 mm
| Red, Blue, Green, White | L84xW60xH60(mm) | 24V | 6.5W/7.2W | - | - | $389.00 | Ships in 2-3 weeks | |
|
LS-CXL-0036High precision coaxial light, 74 x 50 x 50 mm
| Red, Blue, Green, White | L74xW50xH50(mm) | 24V | 4.4W/4.4W | - | - | $329.00 | Ships in 2-3 weeks |
Coaxial light or dome light?
A coaxial light sends light down the camera axis through a half-mirror (beam splitter). Flat, mirror-like surfaces reflect it straight back, so they look evenly bright, and any dent, scratch, print or contamination that scatters light looks dark. Use it for flat shiny parts: wafers, glass, polished metal, film, PCB pads and laser marks on flat metal.
A dome light lights the part from every direction at once. It suits shiny parts that are curved, crinkled or uneven (cans, foil packs, ball bearings), where a coaxial light would only light the flat spots.
Choosing a coaxial light
- Size: the emitting window must be larger than the field of view, since only the part under the window is lit evenly.
- Working distance: the camera looks through the light, so the light sits between lens and part; check the room.
- Colour: red for general use, blue for fine scratches on metal, white for colour cameras.
- Brightness: the half-mirror loses part of the light, so coaxial lights need more power than a ring light for the same image; a strobing controller helps on moving parts.
