Representative photo of this series
Coaxial lights
Collimated coaxial light (LS-CXL-0115)
Model LS-CXL-0115
- ColourWhite
- Emitting area100 x 100 mm
- SizeL194xW110xH106(mm)
- Power6W
$1,139.00
Ships in 2-3 weeks
1.25 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Coaxial light with a special optical path design for high parallelism, using high-power LEDs for high luminance; the uniform light rays are easy for software to recognize.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-CXL-0115 |
|---|---|
| Light spot (LS-CXL-0113-W) | WD 25: dia. 50, 16350 lx; WD 100: dia. 52, 9330 lx; WD 200: dia. 55, 6435 lx |
| Customizable | viewport, length and width, colour and colour temperature, cable length, installation method |
| Note | UV & IR light can be customized as required. |
| Viewport (camera hole) | 110 x 90 mm |
Interfaces and I/O
| Cable (mm) | 500 (drawings) |
|---|---|
| Extension cable options | PVC extension cable (high flexibility, bending and heat resistant, for use inside equipment) or high-flexibility extension cable (harder and more abrasion resistant than PVC, for drag-chain production lines) |
Light
| Custom wavelengths | UV & IR light can be customized as required |
|---|---|
| LED colour | R(red)/W(white) |
| Emitting surface (mm) | 100 x 100 |
Environment and compliance
| Operating temperature | 0-50 °C |
|---|---|
| Operating humidity | 20-85% (non-condensing) |
| Lifespan | 50000 h (to 50% of factory-default luminance) |
Electrical
| Adapted controller | Constant current controller |
|---|---|
| Current | 2000mA |
| Power | 6W |
| Supply voltage (derived) | 24 V DC, derived: all 58 coaxial lights of this range that state a voltage are rated 24 V |
Mechanical
| Dimension | L194xW110xH106(mm) |
|---|---|
| Mounting holes | 4-M4 depth 4.5; 2×2-M4 depth 4 |
| Shipping weight | 1.25 kg |
