Hikrobot HK-360-X-15 1.6 MP smart code reader

Fixed code readers

Hikrobot MV-ID5050-08M- XT 8 mm, 5 MP global-shutter industrial code reader

Model MV-ID5050-08M- XTHikrobot

Resolution2432 × 2048
SensorCMOS, global shutter
InterfaceFast Ethernet(100 Mbit/s)
Speed50 fps
Lens mountM12
Mono / colourMono

$1,969.00

Ships in 2-3 weeks

0.49 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-ID5050-08M- XT 8 mm, 5 MP global-shutter industrial code reader. Built-in deep-learning decoding algorithm: robust under a wide range of difficult conditions High-performance 5 MP sensor: wide field of view and excellent image quality

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-ID5050-08M- XT
Brand	Hikrobot
Lens cap	Semi-polarizing lens cover, Clear and full-polarizing lens covers optional
Indicator	Power indicator PWR, Network indicator LNK/ACT, Status indicator STS, Result indicator OK/NG

Optics

Focal length	8 mm

Sensor and imaging

Symbologies	1D code: Code 39, Code 93, Code 128, CodaBar, EAN8, EAN13, UPCA, UPCE, ITF14, ITF25, Matrix 25, MSI, China Post, Code 11, Industrial 2of5, Pharmacode, etc.; 2D code: QR Code, Data Matrix, MicroQR, AZTEC, HanXin, etc.; Stacked code: PDF417, etc.
Max. frame rate	50 fps
Max. reading speed	60 codes/sec
Sensor type	CMOS, global shutter
Pixel size	3.4 μm × 3.4 μm
Sensor size	2/3”
Resolution	2432 × 2048
Exposure time	60 μs ~ 1 sec
Gain	0 dB ~ 18 dB
Mono/color	Mono

Interfaces and I/O

Communication protocol	SmartSDK, TCP Client, Serial, FTP, TCP Server, Profinet, Melsec/SLMP, Ethernet/IP, ModBus, Fins, UDP
Data interface	Fast Ethernet(100 Mbit/s)
Digital I/O	17-pin M12 connector for power and I/O: 3 non-isolated inputs (LineIn 0/1/2), 3 non-isolated outputs (LineOut 3/4/5), 1× RS-232 input, 1× RS-232 output
Client software	IDMVS

Light

Light source	Focused white light, Optional focused red/blue/IR/UV

Environment and compliance

Ingress protection	IP67 (under proper installation of waterproof lens cap)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Electrical

Power supply	24 VDC
Power consumption	Avg. power: 10.6 W @ 24 VDC (built-in light on); Max. power: 45 W @ 24 VDC (built-in light on)

Mechanical

Lens mount	M12-mount, mechanical focus
Dimension	65.2 mm×65.2 mm×47 mm
Weight	Approx. 280 g (0.6 lb.)
Shipping weight (estimated)	0.49 kg

Downloads

Datasheet (PDF, Chinese)MV-ID5050-08M- XT · 610 KB

Features

Built-in deep-learning decoding algorithm: robust under a wide range of difficult conditions
High-performance 5 MP sensor: wide field of view and excellent image quality
Single cable provides a rich I/O interface for multiple input and output signals
14-LED composite light with fast switching between polarized and non-polarized modes
Top ring indicator and dual side-strip result indicators show working status at a glance
External dual LED aimer for easy alignment
