Hikrobot MV-CU200-20GC 20MP Area Scan Camera, GigE, AR2020, Color

Area scan cameras

Hikrobot MV-CU050-30GM 5MP Area Scan Camera, GigE, AR0521, Mono

Model MV-CU050-30GMHikrobot

Resolution2592 × 1944
SensorCMOS, rolling shutter
Speed24 fps @ 2592 × 1944 Mono 8
Lens mountC-mount
Mono / colourMono
Pixel size2.2 μm × 2.2 μm

$199.00

Ships in 2-3 weeks

0.24 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CU050-30GM 5MP Area Scan Camera, GigE, AR0521, Mono. Adopts low power consumption design with stable performance. Supports auto and manual adjustment of gain, exposure time, etc.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CU050-30GM
Brand	Hikrobot
Compatibility	GigE Vision V2.0, GenICam

Sensor and imaging

Sensor type	CMOS, rolling shutter
Sensor model	AR0521
Pixel size	2.2 μm × 2.2 μm
Sensor size	1/2.5"
Resolution	2592 × 1944
Max. frame rate	24 fps @ 2592 × 1944 Mono 8
Dynamic range	63 dB
SNR	37 dB
Gain	0 dB to 15 dB
Exposure time	21 μs to 1 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono/color	Mono
Pixel format	Mono 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2
Decimation	Supports 1 × 1, 2 × 2
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS or third-party software meeting with GigE Vision Protocol

Environment and compliance

Ingress protection	IP30 (under proper lens installation and wiring)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 80% RH (no condensation)
Certification	RoHS

Computing

Operating system	32/64-bit Windows XP/7/10/11, 32/64-bit Linux, and 64-bit MacOS

Electrical

Power supply	9 VDC to 24 VDC, supports PoE
Power consumption	Typ. 1.78 W @ 12 VDC

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7")
Weight	Approx. 100 g (0.2 lb.)
Shipping weight (estimated)	0.24 kg

Downloads

Features

Adopts low power consumption design with stable performance.
Supports auto and manual adjustment of gain, exposure time, etc.
Supports hardware trigger, software trigger, free run, etc.
Adopts GigE interface and max. transmission distance of 100 meters without relay.
Compatible with GigE Vision V2.0 Protocol, GenlCam Standard, and third-party software based on the protocol and standard.
