Hikrobot MV-CT3CA0050/G/C/NN 5MP Area Scan Camera, 3rd Gen., XoCLink, MINI, C-mount, color
  • Hikrobot MV-CT3CA0050/G/C/NN 5MP Area Scan Camera, 3rd Gen., XoCLink, MINI, C-mount, color
  • MV-CT3CA0050/G/C/NN dimensions (mm)

Area scan cameras

Hikrobot MV-CT3CA0050/G/C/NN 5MP Area Scan Camera, 3rd Gen., XoCLink, MINI, C-mount, color

Model MV-CT3CA0050/G/C/NNHikrobot

  • Resolution2448 × 2048
  • SensorCMOS, global shutter
  • InterfaceXoCLink
  • Speed80 fps @ 2448 × 2048 Bayer GR 8
  • Lens mountC-mount
  • Mono / colourColor
  • Lowest dynamic range of the 16 models in its series: 60.6 dB (shared with 3 other models)
$819.00

Ships in 2-3 weeks

0.23 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Ask an engineerBrowse Area scan cameras

MV-CT3CA0050/G/C/NN: resolution 2448 x 2048; sensor type CMOS, global shutter; sensor size 2/3"; dynamic range 60.6 dB; mono/color Color.

Hikrobot MV-CT3CA0050/G/C/NN 5MP Area Scan Camera, 3rd Gen., XoCLink, MINI, C-mount, color. Adopts compact and lightweight design with flexible mounting options, applicable to high-speed motion scenes. Low power consumption design reduces heat flux density, resulting in low temperature drift.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelMV-CT3CA0050/G/C/NN
BrandHikrobot
CompatibilityGenICam, XoCLink

Sensor and imaging

Sensor typeCMOS, global shutter
Sensor modelStacked BSI
Pixel size3.45 μm × 3.45 μm
Sensor size2/3"
Resolution2448 × 2048
Max. frame rate80 fps @ 2448 × 2048 Bayer GR 8
Dynamic range60.6 dB
SNR43.8 dB
Gain0 dB to 24 dB
Exposure time5 μs to 10 sec
Exposure modeOff/Once/Continuous exposure mode
Mono/colorColor
Pixel formatMono 8; Bayer GR 8/10/12; RGB 8, BGR 8
BinningSupports 1 × 1, 2 × 2, 4 × 4
DecimationSupports 1 × 1, 2 × 2, 4 × 4
Reverse imageSupports horizontal and vertical reverse image output

Interfaces and I/O

Data interfaceXoCLink
Digital I/O8-pin M8 A-Code aviation connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 2 (Line 2/5).
Client softwareMVS

Environment and compliance

Ingress protectionIP40 (under proper lens installation and wiring)
TemperatureWorking temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity20% RH to 95% RH (no condensation)

Computing

Operating system32/64-bit Windows 7/10, 64-bit Windows 11

Electrical

Power supply9 VDC to 24 VDC, supports PoC
Power consumptionTyp. 1.7 W @ 12 VDC

Mechanical

Lens mountC-mount
Dimension (without lens)29 mm × 29 mm × 33 mm (1.1" × 1.1" × 1.3")
WeightApprox. 90 g (0.2 lb.)
Shipping weight (estimated)0.23 kg

Engineering data

Field of view and resolution with the MV-CT3CA0050/G/C/NN

Worked out from this camera's own sensor: the field of view and the size one pixel covers on the part, for common lenses and working distances.

Sensor area8.45 × 7.07 mm2/3" optical format
Lens image circle needed≥ Ø 11 mmC-mount
Pixel pitch3.45 µm2448 x 2048 px
Image data at max frame rate401 MB/sCalculated: 80 fps × 2448 × 2048 px at 8 bit
With a 16 mm lens at 500 mm264 × 221 mm0.108 mm per pixel
Dynamic range60.6 dB
SNR43.8 dB
Power consumption1.7 Wtyp. at 12 V DC
ShutterGlobal
Exposure range5 µs to 10 s
Weight90 gapprox.
Field of view (width × height) and object pixel size by lens focal length and working distance
LensAt 300 mmAt 500 mmAt 1000 mm
8 mm317 × 265 mm0.129 mm per pixel528 × 442 mm0.216 mm per pixel1056 × 884 mm0.431 mm per pixel
12 mm211 × 177 mm0.086 mm per pixel352 × 295 mm0.144 mm per pixel704 × 589 mm0.288 mm per pixel
16 mm158 × 133 mm0.065 mm per pixel264 × 221 mm0.108 mm per pixel528 × 442 mm0.216 mm per pixel
25 mm101 × 84.8 mm0.041 mm per pixel169 × 141 mm0.069 mm per pixel338 × 283 mm0.138 mm per pixel
35 mm72.4 × 60.6 mm0.03 mm per pixel121 × 101 mm0.049 mm per pixel241 × 202 mm0.099 mm per pixel
50 mm50.7 × 42.4 mm0.021 mm per pixel84.5 × 70.7 mm0.035 mm per pixel169 × 141 mm0.069 mm per pixel

Thin-lens approximation: field of view ≈ sensor size × working distance ÷ focal length. Object pixel size = field-of-view width ÷ horizontal pixels; a feature should span about 3-4 pixels to be measured reliably.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Lenses for this C-mount camera

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Covers up to 11 mm diagonal; this camera's sensor is 11 mm

Cables and frame grabbers
