Hikrobot MV-CS004-10UM 0.4MP Area Scan Camera, USB3.0, IMX287, 2nd Gen., Mono

Area scan cameras

Hikrobot MV-CS016-10UM V5 1.6MP Area Scan Camera, USB3.0, V5, Mono

Model MV-CS016-10UM V5Hikrobot

Resolution1440 × 1080
SensorCMOS, global shutter
InterfaceUSB3.0, compatible with USB2.0
Speed249.1 fps @ 1440 × 1080 Mono 8
Lens mountC-mount
Mono / colourMono

$409.00

Ships in 2-3 weeks

0.21 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CS016-10UM V5 1.6MP Area Scan Camera, USB3.0, V5, Mono. Adopts brand new design to reduce power consumption. Supports sequencer, contrast ratio, white balance, Gamma correction, etc.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CS016-10UM V5
Brand	Hikrobot
Compatibility	USB3.0 Vision, GenlCam
EMVA quantum efficiency	60.00 %
EMVA dark noise	2.1 e- @ 12 bit
EMVA saturation capacity	9.5 ke-

Sensor and imaging

Sensor type	CMOS, global shutter
Sensor model	Sony® IMX273
Pixel size	3.45 μm × 3.45 μm
Sensor size	1/2.9"
Resolution	1440 × 1080
Max. frame rate	249.1 fps @ 1440 × 1080 Mono 8
Dynamic range	70.8 dB
SNR	39.8 dB
Gain	0 dB to 17 dB
Exposure time	UltraShort exposure mode: 1 μs to 14 μs; Standard exposure mode: 15 μs to 10 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono/color	Mono
Pixel format	Mono 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2
Decimation	Supports 1 × 1, 2 × 2
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	USB3.0, compatible with USB2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client software	MVS or third-party software meeting with USB3.0 Vision Protocol

Environment and compliance

Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux

Electrical

Power supply	9 VDC to 24 VDC, supports USB3.0 power supply
Power consumption	Typ. 1.7 W @ 5 VDC (USB3.0 provides power supply)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 80 g (0.18 lb.)
Shipping weight (estimated)	0.21 kg

Downloads

Features

Adopts brand new design to reduce power consumption.
Supports sequencer, contrast ratio, white balance, Gamma correction, etc.
Supports hardware trigger, software trigger, and free run.
Compact design with mounting holes on panels for flexible mounting from 4 sides.
Compatible with USB3.0 Vision Protocol, GenlCam Standard, and the third-party software based on the protocol and standard.
