Line scan cameras
Hikrobot MV-CL044-91NC 4k 7μm, 2.5G, color
Model MV-CL044-91NCHikrobot
- Resolution4096 ×3
- SensorCMOS
- Lens mountM42
- Mono / colourColor
- Pixel size7 μm × 7 μm
$1,919.00
Ships in 2-3 weeks
0.46 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CL044-91NC 4k 7μm, 2.5G, color. Adopts 2.5 GigE interface to transmit data, and supports max. line rate of 75.3 kHz and peak value of 100 kHz. Supports RGB true color image output.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CL044-91NC |
|---|---|
| Brand | Hikrobot |
| Image mode | Supports 1-Line |
| Compatibility | GigE Vision V2.0, GenICam |
Sensor and imaging
| Sensor type | CMOS |
|---|---|
| Pixel size | 7 μm × 7 μm |
| Resolution | 4096 ×3 |
| Max. line rate | Full resolution: 75.3 kHz @ Mono 8/Bayer RG 8, 25.1 kHz @ RGB 8/BGR 8, 37.7 kHz @ Bayer RG 10; Line rate after ROI: Max. 100 kHz (3080 P and below) |
| Dynamic range | 61.3 dB |
| SNR | 40.3 dB |
| Gain | 1.0 ×, 2.0 ×, 3.0 ×, 4.0 × |
| Exposure time | 1 μs to 10 ms |
| Exposure mode | Off/Once/Continuous exposure mode, and supports trigger-width exposure |
| Pixel format | RGB 8, BGR 8; Bayer RG 8/10; Mono 8 |
| Binning | Supports 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4 |
| Reverse image | Not supported |
| Mono/color | Color |
Interfaces and I/O
| Data interface | 2.5 Gigabit Ethernet (2500 Mbit/s), compatible with Gigabit Ethernet (1000 Mbit/s) and Fast Ethernet (100 Mbit/s) |
|---|---|
| Digital I/O | 12-pin P10 connector provides power and I/O: bi-directional configurable I/O × 4 (Line 0/1/3/4) and support single-ended/differential I/O signal |
| Client software | MVS or the third-party software meeting with GigE Vision protocol |
Environment and compliance
| Ingress protection | IP40 (under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: –20 °C to 55 °C (–4 °F to 131 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F) |
| Humidity | 20% RH to 80% RH (no condensation) |
| Certification | CE, RoHS, KC |
Computing
| Operating system | 32/64-bit Windows 7/10, 64-bit Windows 11 and 32/64-bit Linux |
|---|
Electrical
| Trigger mode | External trigger, internal trigger |
|---|---|
| External trigger mode | Line trigger, frame trigger, line + frame trigger |
| Power supply | 12 VDC to 24 VDC, supports PoE |
| Power consumption | Typ. 7.2 W @ 12 VDC |
Mechanical
| Lens mount | M42*1.0, flange back length 12 mm; Connecting to F-mount, C-mount, and other lenses via adapter ring |
|---|---|
| Dimension | 62 mm × 62 mm × 46.1 mm (2.4" × 2.4" × 1.8") |
| Weight | Approx. 260 g (0.6 lb.) |
| Shipping weight (estimated) | 0.46 kg |
