Hikrobot MV-CL022-91GM 2K GigE Line Scan Cameras, Mono
  • Hikrobot MV-CL022-91GM 2K GigE Line Scan Cameras, Mono
  • MV-CL022-91GM dimensions (mm)

Line scan cameras

Hikrobot MV-CL022-91GM 2K GigE Line Scan Cameras, Mono

Model MV-CL022-91GMHikrobot

  • Resolution2048 × 1
  • SensorCMOS
  • Lens mountM42
  • Mono / colourMono
  • Pixel size14 μm × 14 μm
$1,459.00

Ships in 2-3 weeks

0.49 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CL022-91GM 2K GigE Line Scan Cameras, Mono. Supports image high-bandwidth, trigger-width exposure. Supports manual adjustment for Gamma correction, PRNU correction, LUT, black level offset, etc.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelMV-CL022-91GM
BrandHikrobot
CompatibilityGigE Vision V2.0, GenICam

Sensor and imaging

Sensor typeCMOS
Pixel size14 μm × 14 μm
Resolution2048 × 1
Max. line rateStandard mode: 56 kHz @ Mono 8, 28 kHz @ Mono 10/12; High-bandwidth mode: 100 kHz @ Mono 8/10/12
Dynamic range63.4 dB
SNR39.4 dB
Gain1.0 ×, 1.4 ×, 1.6 ×, 2.4 ×, 3.2 ×
Exposure time5 μs to 10 ms
Exposure modeOff/Once/Continuous exposure mode, and supports trigger-width exposure
Pixel formatMono 8/10/12
BinningSupports 1 × 1, 1 × 2, 2 × 1, 2 × 2
Reverse imageSupports horizontal reverse image output
Mono/colorMono

Interfaces and I/O

Data interfaceGigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Digital I/O12-pin P10 connector provides power and I/O: Configurable input/output × 4 (Line 0/1/3/4) and single-ended/differential is supported.
Client softwareMVS or the third-party software meeting with GigE Vision protocol

Environment and compliance

Ingress protectionIP40 (under proper lens installation and wiring)
TemperatureWorking temperature: –20 °C to 55 °C (32 °F to 131 °F); Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity5% RH to 90% RH (no condensation)
CertificationCE, RoHS, KC

Computing

Operating system32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux

Electrical

Trigger modeExternal trigger, internal trigger
External trigger modeLine trigger, frame trigger, line + frame trigger
Power supply12 VDC to 24 VDC, supports PoE
Power consumptionTyp. 5 W @ 12 VDC

Mechanical

Lens mountM42*1.0, flange back length 12 mm, applicable to F-mount, C-mount and others via lens adapter
Dimension62 mm × 62 mm × 41 mm (2.4" × 2.4" × 1.6")
WeightApprox. 280 g (9.9 lb.)
Shipping weight (estimated)0.49 kg
