Area scan cameras
Hikrobot MV-CH100-60UC 10MP Area Scan Camera, Color
Model MV-CH100-60UCHikrobot
- Resolution4096 × 2460
- SensorCMOS, global shutter
- InterfaceUSB 3.0, compatible with USB 2.0
- Speed36 fps @ 4096 × 2460 Bayer GR 8
- Lens mountC-mount
- Mono / colourColor
$2,119.00
Ships in 2-3 weeks
0.26 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Hikrobot MV-CH100-60UC 10MP Area Scan Camera, Color. Supports auto or manual adjustment of gain, exposure time, white balance, LUT, Gamma correction, etc. Supports customized ROI, horizontal and vertical reverse image output.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-CH100-60UC |
|---|---|
| Brand | Hikrobot |
| Compatibility | USB3 Vision, GenICam |
Sensor and imaging
| Sensor type | CMOS, global shutter |
|---|---|
| Sensor model | Stacked BSI |
| Pixel size | 3.45 μm × 3.45 μm |
| Sensor size | 1" |
| Resolution | 4096 × 2460 |
| Max. frame rate | 36 fps @ 4096 × 2460 Bayer GR 8 |
| Dynamic range | 58.2 dB |
| SNR | 43 dB |
| Gain | 0 dB to 24 dB |
| Exposure time | 80 μs to 10 sec |
| Exposure mode | Off/Once/Continuous exposure mode |
| Mono/color | Color |
| Pixel format | Mono 8/10/12; Bayer GR 8/10/10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed; RGB 8, BGR 8 |
| Binning | Supports 1 × 1, 2 × 2, 4 × 4 |
| Decimation | Supports 1 × 1, 2 × 2, 4 × 4 |
| Reverse image | Supports horizontal and vertical reverse image output |
Interfaces and I/O
| Data interface | USB 3.0, compatible with USB 2.0 |
|---|---|
| Digital I/O | 6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2). |
| Client software | MVS or third-party software meeting with USB3 Vision Protocol |
Environment and compliance
| Ingress protection | IP40 (under proper lens installation and wiring) |
|---|---|
| Temperature | Working temperature: –10 °C to 50 °C (14 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) |
| Humidity | 20% RH to 95% RH (no condensation) |
| Certification | CE, RoHS, KC |
Computing
| Operating system | 32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux |
|---|
Electrical
| Power supply | 9 VDC to 24 VDC, supports USB power supply |
|---|---|
| Power consumption | Typ. 4.0 W @ 5 VDC (USB 3.0 provides power supply) |
Mechanical
| Lens mount | C-mount |
|---|---|
| Dimension | 29 mm × 44 mm × 59 mm (1.1" × 1.7" × 2.3") |
| Weight | Approx. 113 g (0.2 lb.) |
| Shipping weight (estimated) | 0.26 kg |
