Manual XZ vertical-lift stage, 40 / 60 mm, 40 mm (LS-MNT-0232)
Model LS-MNT-0232
- MaterialAluminum alloy, anodized
- Load19.2 N (2 kgf)
- TypeManual slide stages
- DriveDifferential head
$269.00
In stock - ships the same business day (5 available, order by 2 PM ET)
0.53 kg shipping weight
Volume pricing, Net 30 terms or a formal quote for purchasing?
Manual XZ vertical-lift stage, 40 / 60 mm. Multi-axis combined precision stages with X and vertical-lift Z adjustment. At a glance: load 19.2 N (2 kgf); size 40 mm.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-MNT-0232 |
|---|---|
| Drive | Differential head |
| Min. scale | 0.01 mm |
Mechanical
| Travel | XY +/-6.5 deg; Z 10 |
|---|---|
| Material | Aluminum alloy, anodized |
| Size | 40 mm |
| Plate size | 40 x 40 mm |
| Load | 19.2 N (2 kgf) |
| Weight | 0.31 kg |
| Shipping weight (estimated) | 0.53 kg |
