Ring Light, 73 mm dia., 90°, IR 940 nm (LS-RNG-0503)
  • Ring Light, 73 mm dia., 90°, IR 940 nm (LS-RNG-0503)
  • LS-RNG-0503 dimensions (mm)

Ring lights

Ring Light, 73 mm dia., 90°, IR 940 nm (LS-RNG-0503)

Model LS-RNG-0503

  • ColourInfrared
  • SizeΦ73 × 17.5 mm
  • Power6.0 W
  • Wavelength940 nm
$239.00

Ships in 2-3 weeks

0.66 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Ring Light, 73 mm dia., 90°, IR 940 nm (LS-RNG-0503)LS-RNG-0503

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-RNG-0503: dimension Φ73 x 17.5 mm, bore dimension Φ36 mm, irradiation angle 90°, LED rows 3, power 6.0 W.

Ring Light, 73 mm dia., 90°, IR 940 nm. Simple, compact structure, easy to install Multiple angles and flexible sizes

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-RNG-0503
Irradiation angle90°

Interfaces and I/O

Connector typeSMR-03V-B
Cable length500 mm

Light

ColorInfrared
Wavelength940 nm
LED rows3
Diffuse plate includedIncluded

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Humidity20% to 85% RH (non-condensing)

Electrical

Power6.0 W
Supply voltage (derived)24 V DC, derived: all 370 lights of this range with the same connector type that state a voltage are rated 24 V

Mechanical

DimensionΦ73 × 17.5 mm
Outer dimensionΦ73 mm
Bore dimensionΦ36 mm
Shipping weight (estimated)0.66 kg

Engineering data

Drive and fit the LS-RNG-0503

Worked out from the printed voltage, power and dimensions: what the light draws and what it needs from a controller.

Supply24 V DC
Current at 24 V250 mACalculated: printed power ÷ supply voltage
Controller channel it needs24 V constant voltage, at least 6 W
Operating temperature0 to 40 °C
Cable length500 mm

Mounting and installation

Cable0.5 mSMR-03V-B connector

As printed in this model's specifications and dimension drawing. Check the drawing in Downloads before you drill a fixture.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Controllers for this light

10 W per channel at 24 V for this 6 W light

8.1 W per channel at 24 V for this 6 W light

7.5 W per channel at 24 V for this 6 W light

20 W per channel at 24 V for this 6 W light

15 W per channel at 24 V for this 6 W light

24 W per channel at 24 V for this 6 W light

Light cables

Other models in the Classic angled ring lights (LS-RNG-S60) series

See all 41 models
ModelSizePowerWavelengthPriceAvailabilityLink
LS-RNG-0503This modelΦ73 × 17.5 mm6.0 W940 nm$239.00 Ships in 2-3 weeks
LS-RNG-0495Φ34 × 19 mm2.2 W$129.00 Ships in 2-3 weeks View
LS-RNG-0494Φ34 ×19 mm1.9 W465 nm$129.00 Ships in 2-3 weeks View
LS-RNG-0496Φ42 × 18 mm2.0 W$139.00 Ships in 2-3 weeks View
LS-RNG-0497Φ52 × 20 mm2.6 W940 nm$169.00 Ships in 2-3 weeks View
LS-RNG-0498Φ52 × 20 mm2.9 W$169.00 Ships in 2-3 weeks View
LS-RNG-0499Φ53 × 17 mm3.5 W$169.00 Ships in 2-3 weeks View
LS-RNG-0504Φ73 × 17.5 mm5.9 W$239.00 Ships in 2-3 weeks View
LS-RNG-0507Φ74 × 20 mm8 W940 nm$239.00 Ships in 2-3 weeks View
LS-RNG-0506Φ74 × 20 mm3.9 W$239.00 Ships in 2-3 weeks View
LS-RNG-0505Φ74 × 20 mm5.7 W940 nm$239.00 Ships in 2-3 weeks View
LS-RNG-0508Φ74 × 20 mm7.8 W$239.00 Ships in 2-3 weeks View
LS-RNG-0513Φ96 × 10 mm2.6 W625 nm$259.00 Ships in 2-3 weeks View
LS-RNG-0502Φ60 × 18 mm3.9 W$259.00 Ships in 2-3 weeks View
LS-RNG-0501Φ60 × 18 mm3.5 W465 nm$259.00 Ships in 2-3 weeks View
LS-RNG-0500Φ60 × 9 mm0.8 W625 nm$259.00 Ships in 2-3 weeks View
LS-RNG-0514Φ96 × 10 mm2.9 W$259.00 Ships in 2-3 weeks View
LS-RNG-0515Φ100 × 18 mm6.9 W625 nm$269.00 Ships in 2-3 weeks View
LS-RNG-0516Φ100 × 18 mm11.4 W$269.00 Ships in 2-3 weeks View
LS-RNG-0511Φ90 × 20 mm7.8 W625 nm$309.00 Ships in 2-3 weeks View
LS-RNG-0509Φ90 × 21 mm7.8 W940 nm$309.00 Quote Ships in 2-3 weeks View
LS-RNG-0512Φ90 × 20 mm9.8 W$309.00 Ships in 2-3 weeks View
LS-RNG-0510Φ90 × 21 mm7.8 W$309.00 Ships in 2-3 weeks View
LS-RNG-0520Φ120 × 32.6 mm19.9 W$319.00 Ships in 2-3 weeks View
LS-RNG-0519Φ120 × 23 mm15 W$319.00 Ships in 2-3 weeks View
