Machine vision lenses
35mm, F2.8, Full Frame φ43.2mm, 29MP Lens, F-Mount (LS-LF3528M-F)
Model LS-LF3528M-F
- Focal length35 mm
- Magnification0.25 x to 0.05 x
- MountF-mount
- SensorFull frame
- Working distance129 mm to 728 mm
- ApertureF2.8 to F16
$1,079.00
In stock - ships the same business day (2 available, order by 2 PM ET)
0.85 kg shipping weight
Volume pricing, Net 30 or a formal quote?
35mm, F2.8, Full Frame φ43.2mm, 29MP Lens, F-Mount. Provides ultra-high consistency of image clarity. Provides ultra-low distortion and high peripheral brightness ratio.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | LS-LF3528M-F |
|---|
Optics
| Focal length | 35 mm |
|---|---|
| F-number | F2.8 to F16 |
| Image size | Φ43.2 mm |
| Optical distortion | 0.40% |
| Magnification range | 0.25 x to 0.05 x |
| Working distance range | 129 mm to 728 mm |
| Iris control | Manual |
| Focus control | Manual |
| Filter thread | M58 × 0.75 |
| Magnification at working distance (mm) | 129: 0.250; 150: 0.221; 200: 0.170; 250: 0.138; 300: 0.117; 350: 0.101; 400: 0.089; 450: 0.080; 500: 0.072; 550: 0.066; 600: 0.060; 650: 0.056; 700: 0.052; 728: 0.050 |
| Object-to-image distance at working distance (mm) | 129: 254; 150: 274; 200: 322; 250: 371; 300: 420; 350: 470; 400: 520; 450: 569; 500: 619; 550: 669; 600: 719; 650: 769; 700: 819; 728: 851 |
| Field of view H x V (mm) at working distance (mm), sensor 36.17 x 24.11 mm | 129: 146.1 x 97.4; 150: 165.3 x 110.2; 200: 213.5 x 142.4; 250: 262.2 x 174.8; 300: 310.3 x 206.9; 350: 358.3 x 238.9; 400: 406.2 x 270.8; 450: 454.1 x 302.7; 500: 501.9 x 334.6; 550: 549.7 x 366.4; 600: 597.4 x 398.3; 650: 645.1 x 430.1; 700: 692.9 x 461.9; 728: 720.6 x 480.4 |
| Field of view H (mm) at working distance (mm), 8k 5 µm sensor | 129: 165.3; 150: 187.0; 200: 241.6; 250: 296.8; 300: 351.3; 350: 405.7; 400: 460.0; 450: 514.2; 500: 568.4; 550: 622.6; 600: 676.7; 650: 730.8; 700: 784.9; 728: 816.2 |
Environment and compliance
| Temperature | –10 °C to 50 °C (14 °F to 122 °F) |
|---|---|
| Certification | RoHS 2.0 |
Mechanical
| Mount | F-mount |
|---|---|
| Flange back length | 46.5 mm |
| Dimension | Φ61 mm × 81.5 mm (Φ2.4" × 3.2") |
| Weight | 536 g (1.2 Ib.) |
| Shipping weight (estimated) | 0.85 kg |
