LS-BAR-0233 — Bar lights. Dimension-based illustration; details and finish are representative.
  • LS-BAR-0233 — Bar lights. Dimension-based illustration; details and finish are representative.
  • LS-BAR-0233 dimensions (mm)
Dimension-based illustration

Dimension-based illustration. Housing dimensions follow this model's printed specifications; LED layout, cable position, finish and light colour are representative.

Bar lights

327 x 32 mm Diffused bar light (LS-BAR-0233)

Model LS-BAR-0233-R

  • ColourRed, Green, Blue, White
  • TypeDiffused
  • Wavelength red620-630 nm
  • Wavelength green520-530 nm
$399.00

Ships in 2-3 weeks

0.6 kg shipping weight

Color

Volume pricing, Net 30 terms or a formal quote for purchasing?

lumaspecvision.com/products/lumaspec-ls-bar-0233

Request a quote

327 x 32 mm Diffused bar light (LS-BAR-0233)LS-BAR-0233-R

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

About 1.2 times the length of the 282 mm version: LS-BAR-0233, the 9.1 W version, has a 327 mm length, in the lower half of the 55 lengths in the series.

LS-BAR-0233: length 327 mm, width 38 mm, emitting width 32 mm, LED rows 5.

Bar light with a flexible size design and patch (SMD) LEDs with a large divergence angle. A high-uniformity diffuse plate is used, so it can also serve as a backlight.

Tracked shipping 3-year warranty Engineer support Net 30 for approved accounts Secure checkout Shipping, warranty, support and payment details
  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

90-day returns Unused items, counted from delivery; free US return label; no restocking fee Return policy

Specifications

General

ModelLS-BAR-0233
Optional accessoriesExtension cable, diffuse plate
Service lifeRed: 60000 h continuous at 25 °C and 50% illumination until 50% decrement; white: 30000 h under the same conditions
Lamp bead rows5
L (mm)327
W (mm)38
H (mm)27

Interfaces and I/O

Cable length500 mm (drawings)
Light cable1

Light

Wavelength red620-630 nm
Wavelength green520-530 nm
Wavelength blue465-475 nm
Colour temperature white6000-6500 K
Emitting width (mm)32

Environment and compliance

Storage temperature-20 to 60 °C
Operating temperature0 to 40 °C
Humidity20-85 %RH (non-condensing)

Electrical

ControllerLS-CTL-S69 series, LS-CTL-S28 series, LS-CTL-S125 series for strobe overdrive with 48 V pulses (the selected controller should match the power of the light source)
Power R (W)9.1
Power G/B/W (W)11.9
Recommended controllerLS-CTL-S69, LS-CTL-S28, LS-CTL-S125 for strobe overdrive with 48 V pulses
Supply voltage24 V DC (inferred: its recommended constant-voltage controllers output 24 V)

Mechanical

Length ruleL = 12 (end plate thickness) + X (emitting length, increases in multiples of 45 mm)
Mounting2 x 2-M3, depth 5 (drawings)
Shipping weight0.60 kg

Engineering data

Drive and fit the LS-BAR-0233

Current at 24 VRed: 379 mAGreen / Blue / White: 496 mACalculated: printed power ÷ supply voltage
Controller channel it needs24 V constant voltage, at least 11.9 W

Mounting and installation

Mounting holes 4 × M3, 2 groups of 2, 5 mm deep
Cable0.5 m

Compatible parts

Fits with this part

Checked with the configurator's fit rules: supply voltage and drive type, and the light's power against the controller's power per channel wherever both are printed.

Build the full system with this part

Complete the setup

This part with the first fit-tested pick from each group below. Swap any of them for another card further down.

Set total $718.00

Controllers for this light

Recommended

This 11.9 W light uses 79 % of one channel (about 15 W, from the rated output)

Recommended

This 11.9 W light uses 79 % of one channel (about 15 W, from the rated output)

Recommended

This 11.9 W light uses 40 % of one channel (about 30 W, from the rated output)

This 11.9 W light uses 63 % of one channel (about 18.8 W, from the rated output)

This 11.9 W light uses 71 % of one channel (about 16.7 W, from the rated output)

This 11.9 W light uses 60 % of one channel (about 20 W, from the rated output)

Before you buy

Questions about the LS-BAR-0233

Answered from this model's printed specifications and our fit tests. Calculated figures say “about”.

Which controller drives the LS-BAR-0233?

Fit-tested for this 11.9 W light: LS-CTL-0150 (maker-recommended; about 15 W per channel, about 21 % headroom), LS-CTL-0375 (maker-recommended; about 15 W per channel, about 21 % headroom) and LS-CTL-0372 (maker-recommended; about 30 W per channel, about 60 % headroom).

What supply voltage and power does the LS-BAR-0233 need?

It runs on 24 V DC (inferred: its recommended constant-voltage controllers output 24 V) and draws 9.1 W (red), 11.9 W (green, blue, white).

Can the LS-BAR-0233 be strobed?

Yes - the controller is LS-CTL-S69 series, LS-CTL-S28 series, LS-CTL-S125 series for strobe overdrive with 48 V pulses (the selected controller should match the power of the light source).

What temperature range is the LS-BAR-0233 rated for?

Its operating temperature range is 0 to 40 °C.

Other models in the Diffused bar light (LS-BAR-S65) series

See all 165 models

How this model compares

  • Compared with LS-BAR-0230: power (red) 9.1 W here, 7.8 W there; power (green, blue, white) 11.9 W here, 10.2 W there.
  • Emitting width 32 mm, the largest of 3 emitting widths in the series (12 to 32 mm); next size down 22 mm (LS-BAR-0232).
ModelSizePriceAvailabilityLink
LS-BAR-0224192 x 32 mm$279.00 Ships in 2-3 weeks View
LS-BAR-0227237 x 32 mm$319.00 Ships in 2-3 weeks View
LS-BAR-0230282 x 32 mm$359.00 Ships in 2-3 weeks View
LS-BAR-0231327 x 12 mm$399.00 Ships in 2-3 weeks View
LS-BAR-0232327 x 22 mm$399.00 Ships in 2-3 weeks View
LS-BAR-0233This model327 x 32 mm$399.00 Ships in 2-3 weeks
LS-BAR-0236372 x 32 mm$439.00 Ships in 2-3 weeks View
LS-BAR-0239417 x 32 mm$569.00 Ships in 2-3 weeks View
LS-BAR-0241462 x 22 mm$579.00 Ships in 2-3 weeks View
