Hikrobot MV-VC2103-128G40-1T VC2100 vision controller, N97, 8GB+128G SSD + 1T HDD, Basic version, PoE supported, No I/O, light and other functions

Name: Hikrobot MV-VC2103-128G40-1T VC2100 vision controller, N97, 8GB+128G SSD + 1T HDD, Basic version, PoE supported, No I/O, light and other functions
Brand: Hikrobot
SKU: MV-VC2103-128G40-1T

Model MV-VC2103-128G40-1T

Hikrobot MV-VC2103-128G40-1T VC2100 vision controller, N97, 8GB+128G SSD + 1T HDD, Basic version, PoE supported, No I/O, light and other functions. New Intel Alder Lake-N platform processor for powerful computing performance 4 GigE ports for fast, stable image transmission

Datasheet (PDF, Chinese) - MV-VC2103-128G40-1T User manual (PDF, Chinese) - MV-VC2103-128G40-1T CAD: 3D STEP + 2D DXF (ZIP) - MV-VC2103-128G40-1T

Features

New Intel Alder Lake-N platform processor for powerful computing performance
4 GigE ports for fast, stable image transmission
Optional built-in USB port or built-in dongle for easy on-site deployment and maintenance

Specifications

Model	MV-VC2103-128G40-1T
Brand	Hikrobot
CPU	Intel® Processor N97
Memory	8GB
Storage	128G SSD + 1T HDD
GPU	Intel® UHD Graphics
Operating system	Unactivated 64-bit Windows 10 LTSC 21H2
Video output	HDMI interface × 1, VGA interface × 1; Supports independent display output at the same time; Max. resolution 1920 × 1080 @ 60 Hz
Digital I/O	Not supported
Network interface	GigE interface × 4, supports PoE (The total loading is 20 W)
USB Interface	USB 2.0 × 2; USB 3.0 × 2
Serial Port	1 × configurable RS-232 (configurable as RS-485/RS-422)
Power supply	24 VDC
Power consumption	71 W
Dimension	160.59 mm × 205.6 mm × 86 mm
Weight	Approx. 2 kg (4.4 lb.)
Temperature	Operating temp. 0 °C to 50 °C, Storage temp.: -30 °C to 70 °C
Humidity	20% RH to 80% RH (no condensation)
Certification	CE, KC
Shipping weight (estimated)	2.90 kg

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Configure a system Selection guide
