510 x 280 mm traditional surface light source (LS-BKL-1187)
  • 510 x 280 mm traditional surface light source (LS-BKL-1187)
  • LS-BKL-1187 dimensions (mm)

Representative photo of this series

Backlights

510 x 280 mm traditional surface light source (LS-BKL-1187)

Model LS-BKL-1187-R

  • ColourRed, Green, Blue, White, Infrared, UV
  • Voltage24 V DC (12 V on request)
  • TypeStandard
  • Width280 mm
$889.00

Ships in 2-3 weeks

3.45 kg shipping weight

Color

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

510 x 280 mm traditional surface light source (LS-BKL-1187)LS-BKL-1187-R

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

LS-BKL-1187: length 510 mm, width 280 mm, height 25 mm, power red 68.8 W.

Surface light with large-area uniform light emission and high-array LED arrangement for high-brightness planar lighting. Mainly used for perspective contour imaging and large-format uniform illumination.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-BKL-1187

Interfaces and I/O

Cable length (mm)500

Electrical

Voltage24 V DC (12 V on request)
Power red (W)68.8
Power white/blue/green (W)86

Mechanical

Width (mm)280
Length (mm)510
Height (mm)25
Mounting16 x dia. 5 through holes
Shipping weight3.45 kg

Engineering data

Drive and fit the LS-BKL-1187

Worked out from the printed voltage, power and dimensions: what the light draws and what it needs from a controller.

Supply24 V DC
Current at 24 V3583 mACalculated: printed power ÷ supply voltage
Controller channel it needs24 V constant voltage, at least 86 W
Cable length500 mm

Mounting and installation

Mounting holes 16 × Ø 5 mmthrough
Cable0.5 m

As printed in this model's specifications and dimension drawing. Check the drawing in Downloads before you drill a fixture.

Compatible parts

Fits with this part

Checked with the configurator's fit rules: lens mount and sensor coverage, supply voltage, power per channel and connector.

Build the full system with this part

Controllers for this light

120 W per channel at 24 V for this 86 W light

120 W per channel at 24 V for this 86 W light

125 W per channel at 24 V for this 86 W light

Same 24 V supply

Same 24 V supply

Same 24 V supply
