Home / Case studies

Application case studies

Real inspection problems, the real images the camera captured, and the exact lighting, lens and camera set-up that solved them, in 3D. Every part in each kit is in our catalog.

  • Electronics (SMT / AOI)
  • Electronics assembly
  • Fasteners and precision machining
  • Food and agriculture
  • Lithium battery manufacturing
  • Pharmaceutical packaging
Camera image from the test: the thread as a silhouette in front of the collimated light. Crests and roots are sharp edges with no shading on the flanks.
Fasteners and precision machining · Gauging

Screw thread pitch to 7 µm

  • Field of view19.34 × 16.21 mm
  • Image2456 × 2058 px
Read the case study →
Board header pins over a backlight (LS-VCM230-120-AL): the bent pins are obvious, and every edge is measurable.
Electronics assembly · Position and angle check

Bent pins on connectors and boards

  • Field of view50.46 × 37.85 mm
  • Image2592 × 1944 px
Read the case study →
Flat dome (LS-2LFX100-C): the weld outline is clear and even.
Lithium battery manufacturing · Surface defect detection

Battery welds and tabs

  • LightFlat dome, 100 × 100 mm emitting
  • Size140 × 140 × 11.5 mm
Read the case study →
Under the RGB AOI light (LS-AOI160, RGB build): each joint's slope shows as colour, so defects stand out as colour changes.
Electronics (SMT / AOI) · Solder joint inspection

PCB solder joints with an RGB AOI light

  • LightAOI, 160 mm outside, 45 mm aperture
  • Height55 mm
Read the case study →
SWIR 1550 nm: two dark bruises with clear borders (marked by the tester).
Food and agriculture · Hidden defect detection

Apple bruises: NIR vs SWIR

  • NIR940 nm
  • SWIR1550 nm
Read the case study →
Under the arch shadowless light (LS-DL12570, white): even light, and the black dirt is the only dark mark.
Pharmaceutical packaging · Contamination and foreign-matter check

Contamination in blister packs

  • LightArch shadowless, 125 × 70 mm emitting
  • Working distance5–50 mm (light spec)
Read the case study →

Don't see your application? Describe your part in a quote request or configure a system step by step.
