Hikrobot MV-ID5030M Industrial Code Reader
Model MV-ID5030MHikrobot
- Resolution2048 × 1536
- SensorCMOS, global shutter
- InterfaceGigE
- Speed60 fps
- Lens mountM12
- Mono / colourMono
$1,969.00
Ships in 2-3 weeks
0.73 kg shipping weight
Not available in the United States. Available for delivery to other countries.
Available in the US - comparable cameras:
Hikrobot MV-ID5030M Industrial Code Reader. Adopts built-in deep learning algorithm to read codes with good robustness. Adopts CMOS global shutter sensor to provide high quality images.
- Same-day shipping on stock itemsTracked UPS or DHL
- 3-year warranty, minimumCovers defects in materials and workmanship
- Expert machine-vision support includedFrom our licensed P.E. engineers
- Volume discounts and Net 30For approved business accounts; purchase orders welcome
- 90-day returnsUnused items; free return label in the US
- Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay
Specifications
General
| Model | MV-ID5030M |
|---|---|
| Brand | Hikrobot |
| Lens cap | Half polarization lens cap by default. Transparent and full polarization lens cap are optional. |
| Indicator | Power indicator (PWR), network indicator (LNK/ACT), and user-defined indicator (U1/U2). |
Optics
| Focal length | 8 mm (0.3") |
|---|
Sensor and imaging
| Symbologies | 1-dimensional codes: Code 39, Code 93, Code 128, CodaBar, EAN 8, EAN 13, UPCA, UPCE, ITF 14, ITF 25, Matrix 25, MSI, China Post, Code 11, and Industrial 25; 2-dimensional codes: QR Code, Data Matrix; Stack codes: PDF 417 |
|---|---|
| Max. frame rate | 60 fps |
| Max. reading speed | 90 codes/sec |
| Sensor type | CMOS, global shutter |
| Pixel size | 2.5 µm × 2.5 µm |
| Sensor size | 1/2" |
| Resolution | 2048 × 1536 |
| Exposure time | 16 μs to 1 sec |
| Gain | 1 dB to 4 dB |
| Mono/color | Mono |
Interfaces and I/O
| Client software | IDMVS |
|---|---|
| Communication protocol | SmartSDK, TCP Client, TCP Server, Serial, FTP, Profinet, Ethernet/IP, MELSEC, ModBus, Fins, SLMP, UDP |
| Data interface | GigE |
| Digital I/O | 12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 3/4/5) × 3, RS-232 input × 1, and RS-232 output × 1. |
Light
| Light source | White light by default. Red/blue/IR light is optional. |
|---|
Environment and compliance
| Certification | CE, FCC, RoHS, KC |
|---|---|
| Ingress protection | IP67 (under proper installation of waterproof lens cap) |
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F) |
| Humidity | 20% to 95% RH, non-condensing |
Electrical
| Power supply | 24 VDC |
|---|---|
| Max. power consumption | 60 W@24 VDC (light source enabled) |
Mechanical
| Lens mount | M12-mount, mechanical autofocus supported. |
|---|---|
| Dimension | 112.5 mm × 65.5 mm × 63.3 mm (4.4" × 2.6" × 2.5") |
| Weight | Approx. 450 g (1.0 lb.) |
| Shipping weight (estimated) | 0.73 kg |
Photo shows a representative model of this series; see the specifications for this model.
