Hikrobot MV-CU013-80UC 1.3MP Area Scan Camera, USB3, SS, Color

Model MV-CU013-80UCHikrobot

Resolution1280 × 1024
SensorCMOS, global shutter
InterfaceUSB3.0, compatible with USB2.0
Speed240.4 fps @1280 × 1024 Bayer BG 8
Lens mountC-mount
Mono / colourColor

$279.00

Ships in 2-3 weeks

0.21 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-CU013-80UC 1.3MP Area Scan Camera, USB3, SS, Color. Supports auto or manual adjustment of gain, exposure time, manual adjustment of LUT, Gamma correction, etc. Supports hardware trigger, software trigger, free run, etc.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-CU013-80UC
Brand	Hikrobot
Compatibility	USB3 Vision, GenlCam

Sensor and imaging

Sensor type	CMOS, global shutter
Sensor model	SS
Pixel size	4.0 μm × 4.0 μm
Sensor size	1/2.7"
Resolution	1280 × 1024
Max. frame rate	240.4 fps @1280 × 1024 Bayer BG 8
Dynamic range	50.6 dB
SNR	38.7 dB
Gain	0 dB to 20 dB
Exposure time	30 μs to 1 sec
Exposure mode	Off/Once/Continuous exposure mode
Mono/color	Color
Pixel format	Bayer BG 8/10/10Packed/12/12Packed
Binning	Supports 1 × 1, 2 × 2, 4 × 4
Decimation	Supports 1 × 1, 2 × 2, 4 × 4
Reverse image	Supports horizontal and vertical reverse image output

Interfaces and I/O

Data interface	USB3.0, compatible with USB2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), and bi-directional non-isolated I/O × 1 (Line 2)
Client software	MVS or third-party software meeting with USB3 Vision Protocol

Environment and compliance

Ingress protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
Humidity	20% to 80% RH, non-condensing
Certification	CE, RoHS, KC

Computing

Operating system	32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS

Electrical

Power supply	9 VDC to 24 VDC, supports USB3.0 power supply
Power consumption	Typ. 1.7 W@5 VDC (USB3.0 provides power supply)

Mechanical

Lens mount	C-mount
Dimension	29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 77 g (0.2 lb.)
Shipping weight (estimated)	0.21 kg

Downloads

Features

Supports auto or manual adjustment of gain, exposure time, manual adjustment of LUT, Gamma correction, etc.
Supports hardware trigger, software trigger, free run, etc.
Adopts compact design for flexible installation.
Compatible with USB3 Vision Protocol, GenlCam Standard, and third-party software based on the protocol and standard.
