Hikrobot MV-CI003-GL-N6 0.3MP LWIR Camera, GigE, EFL 6.3mm
  • Hikrobot MV-CI003-GL-N6 0.3MP LWIR Camera, GigE, EFL 6.3mm
  • MV-CI003-GL-N6 dimensions (mm)

Infrared cameras

Hikrobot MV-CI003-GL-N6 0.3MP LWIR Camera, GigE, EFL 6.3mm

Model MV-CI003-GL-N6Hikrobot

  • Resolution640 × 512
  • SensorVanadium oxide uncooled detector
  • Speed50 fps @ 640 × 512
  • Lens mountM34x0.75
  • Pixel size17 μm
  • Focal length6.3 mm

Price on request

Ships in 2-3 weeks

0.48 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Available in the US - comparable cameras:

Ask an engineerBrowse Infrared cameras

MV-CI003-GL-N6: focal length 6.3 mm, field of view 88.5° x 73.2°, min. operation distance 0.1 m.

Hikrobot MV-CI003-GL-N6 0.3MP LWIR Camera, GigE, EFL 6.3mm. Adopts high-sensitivity vanadium oxide uncooled detector with 0.3 MP. Supports multiple palette modes, grayscale detection, image adjustment, etc.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CERoHSKC

Specifications

General

ModelMV-CI003-GL-N6
BrandHikrobot
NETD< 35 mk (F1.0, 25 °C)
Response time< 10 ms
Image processSupports brightness, contrast, image detail strength, digital noise reduction (spatial and temporal)
Min. operation distance0.1 m
CompatibilityGigE Vision V2.0, GenICam

Optics

Focal length6.3 mm
Field of view88.5° × 73.2°

Sensor and imaging

Sensor typeVanadium oxide uncooled detector
Pixel size17 μm
Resolution640 × 512
Max. frame rate50 fps @ 640 × 512
Pixel formatMono 8/12/14, YUV422_YUYV_Packed

Interfaces and I/O

Data interfaceGigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
Digital I/O6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Client softwareMVS or third-party software meeting with GigE Vision Protocol

Light

Color palettesWhite Hot, Black Hot, Fusion 1, Rainbow, Fusion 2, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice Fire, Rain, Green Hot, Red Hot, Dark Blue

Environment and compliance

Ingress protectionIP40 (under proper lens installation and wiring)
TemperatureWorking temperature: –30 °C to 60 °C (–22 °F to 140 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity20% RH to 90% RH (no condensation)
CertificationCE, RoHS, KC

Computing

Operating system32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux.

Electrical

Power supply9 VDC to 24 VDC, supports PoE
Power consumptionTyp. 2.5 W @ 12 VDC

Mechanical

Lens mountM34*0.75
Dimension58 mm × 58 mm × 115.5 mm (2.3" × 2.3" × 4.5")
WeightApprox. 275 g (0.6 lb.)
Shipping weight (estimated)0.48 kg

Other models in the Long Wave Infrared Camera series

See all 5 models
ModelSizeFocal lengthPriceAvailabilityLink
MV-CI003-GL-N6This model0.3 MP, GigE6.3 mmOn request Ships in 2-3 weeks
MV-CI003-GL-N150.3 MP, GigE15 mmOn request Ships in 2-3 weeks View
MV-CI003-GL-N250.3 MP, GigE25 mmOn request Ships in 2-3 weeks View
MV-CI003-GL-N350.3 MP, GigE35 mmOn request Ships in 2-3 weeks View
MV-CI003-GL-T60.3 MP, GigE6.3 mmOn request Ships in 2-3 weeks View
