Bi-telecentric lens (VCM111B series)
  • Bi-telecentric lens (VCM111B series)
  • LS-VCM111B-150-AL dimensions (mm)

Representative photo of this series

Telecentric lenses

Bi-telecentric lens, 0.123x, WD 301 mm, 1.1", C-Mount (LS-TCL-2494)

Model LS-TCL-2494

  • Magnification0.123x
  • MountC-mount
  • Sensor1.1"
  • Working distance301±4
  • Field of view150
$3,559.00

In stock - ships the same business day (2 available, order by 2 PM ET)

9.24 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Bi-telecentric lens, 0.123x, WD 301 mm, 1.1", C-Mount (LS-TCL-2494)LS-TCL-2494

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Superior bi-telecentric design, distinguished imaging quality

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our licensed P.E. engineers
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items; free return label in the US
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-TCL-2494
FOV with 14.13x10.35 with IMX304 (mm x mm)114.8x84.1

Optics

Magnification (x)0.123
Object field of view (dia. mm)150
Working distance (mm)301±4
Best Aperture (F/#)6.18
MTF30 (lp/mm)>140
Depth of field (mm)±10

Sensor and imaging

Max sensor size (dia. mm)18.4(1.1")
Sensor format1.1"

Interfaces and I/O

Length of I/O (mm)684.2

Mechanical

MountC
Length (mm)365.7
Weight (kg)6.53

Other models in the Bi-telecentric lens (LS-TCL-S72) series

See all 15 models
ModelSize / key dataPriceAvailabilityLink
LS-TCL-2482 0.707x, WD 72 mm, 1.1", C-mount $1,399.00 3 in stock View
LS-TCL-2483 0.509x, WD 111 mm, 1.1", C-mount $1,629.00 2 in stock View
LS-TCL-2484 0.437x, WD 118 mm, 1.1", C-mount $1,769.00 5 in stock View
LS-TCL-2485 0.382x, WD 128 mm, 1.1", C-mount $1,909.00 2 in stock View
LS-TCL-2487 0.286x, WD 159 mm, 1.1", C-Mount $1,949.00 2 in stock View
LS-TCL-2486 0.328x, WD 138 mm, 1.1", C-mount $2,099.00 2 in stock View
LS-TCL-2489 0.229x, WD 230 mm, 1.1", C-Mount $2,249.00 4 in stock View
LS-TCL-2488 0.255x, WD 178 mm, 1.1", C-mount $2,469.00 4 in stock View
LS-TCL-2492 0.165x, WD 251 mm, 1.1", C-Mount $2,849.00 5 in stock View
LS-TCL-2490 0.204x, WD 208 mm, 1.1", C-mount $2,889.00 4 in stock View
LS-TCL-2491 0.185x, WD 238 mm, 1.1", C-mount $3,139.00 2 in stock View
LS-TCL-2493 0.134x, WD 288 mm, 1.1", C-mount $4,059.00 5 in stock View
LS-TCL-2495 0.108x, WD 318 mm, 1.1", C-mount $4,829.00 5 in stock View
LS-TCL-2496 0.076x, WD 410 mm, 1.1", C-mount $6,669.00 3 in stock View
