  • LS-SWL-0153 dimensions (mm)

Thermal, SWIR & UV lenses

17 mm LWIR Thermal Lens (LS-SWL-0153)

Model LS-SWL-0153

  • Focal length17x eyepiece
  • MountM24x8
  • Sensor1/2"
  • TypeThermal (LWIR)
$389.00

Ships in 2-3 weeks

0.13 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

17 mm LWIR Thermal Lens (LS-SWL-0153)LS-SWL-0153

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

17 mm LWIR Thermal Lens. Long-wavelength infrared (LWIR) thermal lenses designed for commercial and military applications. At a glance: focal length 17x eyepiece; sensor 8mmx6mm; mount M24X8(P=1); distortion 1%; dimensions dia. 25 x L20 mm.

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-SWL-0153
SealingFront IP 67
Front lens coatingMulti-layer coating

Optics

Focal length17x eyepiece
Distortion1%
Mechanical back focal length3.26 mm
Focus methodFixed

Sensor and imaging

Sensor8mmx6mm

Mechanical

MountM24X8(P=1)
Dimensionsdia. 25 x L20 mm
Weight<20g
Shipping weight (estimated)0.13 kg

Photo shows a representative model of this series; see the specifications for this model.

Other models in the LWIR Thermal lenses (LS-SWL-S01) series

See all 194 models
ModelSize / key dataPriceAvailabilityLink
LS-SWL-0045 13.5 mm, F1 $339.00 Ships in 2-3 weeks View
LS-SWL-0051 14 mm, F1, M45x1-mount $339.00 Ships in 2-3 weeks View
LS-SWL-0120 13.5 mm, F1.1 $339.00 Ships in 2-3 weeks View
LS-SWL-0077 15 mm, F1 $359.00 Ships in 2-3 weeks View
LS-SWL-0133 15 mm, F1, Flange-mount $359.00 Ships in 2-3 weeks View
LS-SWL-0137 15 mm, F1.0 $359.00 Ships in 2-3 weeks View
LS-SWL-0139 15 mm, F1 $359.00 Ships in 2-3 weeks View
LS-SWL-0147 15 mm, F1 $359.00 Ships in 2-3 weeks View
LS-SWL-0170 16 mm, F1.0 $369.00 Ships in 2-3 weeks View
LS-SWL-0181 16 mm, F1 $369.00 Ships in 2-3 weeks View
LS-SWL-0187 16 mm, F1.0, M45x1-mount $369.00 Ships in 2-3 weeks View
LS-SWL-0006 17 mm, F1.2 $389.00 Ships in 2-3 weeks View
LS-SWL-0021 18 mm, F1 $399.00 Ships in 2-3 weeks View
LS-SWL-0011 19 mm, F1 $409.00 Ships in 2-3 weeks View
LS-SWL-0015 19 mm, F1 $409.00 Ships in 2-3 weeks View
LS-SWL-0036 19 mm, F1 $409.00 Ships in 2-3 weeks View
LS-SWL-0040 19 mm, F1 $409.00 Ships in 2-3 weeks View
LS-SWL-0057 19 mm, F1 $409.00 Ships in 2-3 weeks View
LS-SWL-0082 19 mm, F1, Flange-mount $409.00 Ships in 2-3 weeks View
LS-SWL-0092 19 mm, F1, Flange-mount $409.00 Ships in 2-3 weeks View
LS-SWL-0130 19 mm, F1, Flange-mount $409.00 Ships in 2-3 weeks View
LS-SWL-0150 19-30 mm, F1.1 $409.00 Ships in 2-3 weeks View
LS-SWL-0155 19 mm, F2.2 $409.00 Ships in 2-3 weeks View
LS-SWL-0171 19 mm, F1.2 $409.00 Ships in 2-3 weeks View
