Analog constant-voltage light controller, 400W, 1 channel, 19M-2E connector (LS-CTL-0118)
  • Analog constant-voltage light controller, 400W, 1 channel, 19M-2E connector (LS-CTL-0118)
  • LS-CTL-0118 dimensions (mm)

Light controllers

Analog constant-voltage light controller, 400W, 1 channel, 19M-2E connector (LS-CTL-0118)

Model LS-CTL-0118

  • Input24 VDC
  • ControlNot supported
  • TriggerNot supported
  • OutputConstant voltage 24 V
$229.00

Ships in 2-3 weeks

5.08 kg shipping weight

Volume pricing, Net 30 terms or a formal quote for purchasing?

Request a quote

Analog constant-voltage light controller, 400W, 1 channel, 19M-2E connector (LS-CTL-0118)LS-CTL-0118

Price, lead time and volume pricing by email, usually within one business day.

Add phone, delivery date or notes (optional)

No account needed. We reply within one business day.

Analog constant-voltage light controller, 400W, 1 channel, 19M-2E connector. Light brightness set manually or by external trigger Up to 17 A output current per channel

  • Same-day shipping on stock itemsTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; restocking fee up to 15% may apply
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

ModelLS-CTL-0118
Lighting modeAnalog
PWM frequencyNot supported
Dimming modePanel knob
Lighting response timeNot supported
Cooling modeForced cooling (built-in fan)

Interfaces and I/O

Communication protocolNot supported
Applicable productRing light, Bar light, Flat light, Coaxial light, Standard line light
Power supply interfaceAC socket
Console interfaceNot supported
Digital I/ONot supported
Lighting output connector19M-2E

Light

Brightness levelStepless dimming

Environment and compliance

TemperatureWorking temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage temperature: –20 °C to 60 °C (–4 °F to 140 °F)
Ingress protectionIP30 (when properly installed)
Humidity20% RH to 85% RH (no condensation)
CertificationCE, RoHS

Electrical

Drive modeConstant voltage
Strobe overdriveNot supported
Channel1
Trigger modeNot supported
Input voltage24 VDC
Input current3.5 A
Output current17 A max
Output power400 W max
Output current for each channel17 A max
Trigger inNot supported
Trigger outNot supported

Mechanical

Dimension287 mm × 243.1 mm × 87 mm
Shell materialGalvanized steel sheet
WeightApprox. 3560 g
Shipping weight (estimated)5.08 kg
