CCTV lenses
16-1060 mm, 1/1.7", 3 MP, C-mount Motorized Zoom Lens (LS-SMZ161060DJGIR-2M)
Model LS-SMZ161060DJGIR-2M
16-1060 mm, 1/1.7", 3 MP, C-mount Motorized Zoom Lens. 64x motorized zoom lens, 16-1060 mm F3.5-10.5 DC auto iris, for 1/1.7" cameras (covers 1/1.8", 1/2"), IR-corrected, for long-range highway, rail, power station, city, border, mountain and river surveillance. At a glance: focal length 16-1060mm ( 64X ); format 1/1.7"; resolution 3 Megapixel; aperture F3.5-10.5 DC Iris; mount C.
Features
- Resolution: 2 megapixel, covers 1080P and 720P
- Focal length 16-1060 mm (64x)
- Large format: 1/1.7", covers 1/1.8", 1/2"
- Compact size for special applications
- Anti-fog and temperature compensation optional
Specifications
| Model | LS-SMZ161060DJGIR-2M |
|---|---|
| Resolution | 3 Megapixel |
| IR correction | IR |
| Format | 1/1.7" |
| Focal length | 16-1060mm ( 64X ) |
| Aperture | F3.5-10.5 DC Iris |
| Angle of view (1/1.7") | W: 32.1 x 28.2 x 16.1 T: 0.51 x 0.45 x 0.25 |
| Angle of view (1/1.8") | W: 30.2 x 26.5 x 15.1 T: 0.48 x 0.42 x 0.24 |
| M.O.D. | 5m |
| Filter size | M113 x P=1mm |
| ND filter | (Optional) |
| Size | 388 x 135 x 150mm |
| Back focal length (optical) | 55mm |
| Mount | C |
| Weight | 6kg |
| Features | Anti-fog (optional); temperature compensation (optional) |
| Coating | 400~950 nm |
| Shipping weight (estimated) | 8.50 kg |
Applications
- Highway
- Train
- Power station
- City
- Border
- Mountain
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
