10-200 mm, 1/2", 2 MP, C-mount Motorized Zoom Lens (LS-SMZ10200DPIR-2M)
Model LS-SMZ10200DPIR-2M
10-200 mm, 1/2", 2 MP, C-mount Motorized Zoom Lens. Discontinued (end of life; restart MOQ 1000 pcs). 2.0 megapixel 10-200 mm motorized zoom lens with a 1/2" format covering 1/2", 1/2.5" and 1/2.7"; IR-corrected, with preset function. At a glance: focal length 10-200 mm; format 1/2"; resolution 2.0 Megapixel; aperture F2.0 DC Iris; mount C.
Features
- High resolution: 2.0 megapixel can cover 1080P, 720P
- Focal length: 10-200 mm suitable for short distance.
- Large format: 1/2" can cover 1/2", 1/2.5", 1/2.7"
- IR correction: 24h day & night vision
- Preset function: Preset function makes auto-run.
Specifications
| Model | LS-SMZ10200DPIR-2M |
|---|---|
| Resolution | 2.0 Megapixel |
| IR correction | IR |
| Format | 1/2" |
| Focal length | 10-200 mm |
| Aperture | F2.0 DC Iris |
| Angle of view (1/2") | 42.8 x 2.3 deg |
| M.O.D. | 1.5 m |
| Size | dia. 78 x 92 x 160 mm |
| Preset | Yes |
| Mount | C |
| Weight | 880 g |
| Shipping weight (estimated) | 1.33 kg |
Applications
- Highways
- Railways
- Power stations
- Forests
- City surveillance
- Borders
