Cables
Camera Data Cable, 850 nm (LS-AC10G-SFP-850-LC)
Model LS-AC10G-SFP-850-LC
Camera Data Cable, 850 nm. Complies with IEEE802.3ae protocol standard, and supports 10 GigE optical-fiber access. High density, low power consumption, and high cost-effectiveness.
Features
- Complies with IEEE802.3ae protocol standard, and supports 10 GigE optical-fiber access.
- High density, low power consumption, and high cost-effectiveness.
- Improves EMI performance with its metal shell and supports hot plug.
- With the central wavelength of 850 nm and the duplex LC interface, it supports connecting to 10 GigE cameras with the optical fiber interface in machine vision application.
Specifications
| Model | LS-AC10G-SFP-850-LC |
|---|---|
| Packaging form | SFP+ |
| Interface type | Duplex LC |
| Central wavelength | 850 nm |
| Transmission speed | 10.3125 Gbps |
| Transmission distance | 300 m |
| Transmit power | –6.5 dBm to –1 dBm |
| Received power | –11.1 dBm |
| Working temperature | –20 °C to 75 °C (–4 °F to 167 °F) |
| Certification | RoHS |
| Packaging | Individual package |
| Shipping weight (estimated) | 0.31 kg |
Complete the station
Drive the light from a light controller and pair it with a lens for your field of view and working distance.
Light controllers LensesSelection guide
