3D depth camera (LS-8xx / LS-461), 1.2 MP (LS-815-E1)
Model LS-815-E1
3D depth camera IP65 is waterproof, dustproof.Meets IEC standard 60529.
Features
- Maximum range of single camera: 500mm*500mm*500mm.
- Up to 8 cameras online, maximum range: 2000mm*2000mm* 2000mm.
- State of use: static measurement.
- Upgraded SGBM algorithm with built-in hardware lSP.
- Match SDK and RVS software.
Specifications
| Model | LS-815-E1 |
|---|---|
| Measurement range(mm) | 400 ~ 8000 |
| FOV (H/V) | 60°/48° |
| Z Accuracy(mm) | 1.56mm@1000mm |
| X/Y Accuracy(mm) | 3.2mm@1000mm |
| Power&Trigger | 8-pin aviation plug |
| Working distance | 0.4m-8m |
| Accuracy (Z) | 1.56mm@1000mm; 1.80mm@1500mm |
| Accuracy (X,Y) | 3.2mm@1000mm; 4.8mm@1500mm |
| Depth resolution | 1280*960 |
| RGB resolution | 2560*1920 |
| Power Supply | DC 24V / IEEE802.3af/at PoE |
| Power supply and trigger interface | 8 pin aviation interface |
| Data interface | Gigabit Ethernet M12 X-Code aviation interface |
| Power consumption | 5.0W ~ 11.3W |
| Temperature | Storage:-20℃~55℃; Controls:-10℃~50℃ |
| Protection level | IP65 |
| Size | 145mm*35mm*90mm |
| Weight | 620g |
| Voltage | DC 24V / IEEE802.3af/at PoE |
