APS-H telecentric lenses

Telecentric and bi-telecentric lenses keep magnification constant through the depth of field, so parts measure the same size wherever they sit. Lenses rated for APS-H sensors cover an image circle of at least 34.5 mm, so they also suit smaller sensors; on a larger sensor the corners go dark (vignetting).

All telecentric lenses · 4/3-inch telecentric lenses · 1.1-inch telecentric lenses · 1-inch telecentric lenses · 2/3-inch telecentric lenses · 1/1.8-inch telecentric lenses · 1/2-inch telecentric lenses · 1/2.5-inch telecentric lenses · APS-C telecentric lenses · Full frame telecentric lenses

197 models Configure a systemAll lenses
APS-H telecentric lenses

1-24 of 197 models

Products

Compare
LS-TCL-08620.163x bi-telecentric lens, WD 410 mm 0.163xF-mountAPS-H410±6 mmF7.571 MP$6,160.00 Ships in 3-4 weeks
LS-TCL-08640.181x bi-telecentric lens, WD 372 mm 0.181xM42APS-H372±5 mm6.571 MP$5,500.00 Ships in 3-4 weeks
LS-TCL-08770.26x bi-telecentric lens, WD 300 mm 0.26xF-mountAPS-H300±5 mmF13.171 MP$3,960.00 Ships in 3-4 weeks
LS-TCL-08610.151x bi-telecentric lens, WD 338 mm 0.151xM42APS-H338±5 mm6.571 MP$8,000.00 Ships in 3-4 weeks
LS-TCL-08680.205x bi-telecentric lens, WD 330 mm 0.205xF-mountAPS-H330±5 mmF6.571 MP$5,280.00 Ships in 3-4 weeks
LS-TCL-08850.287x bi-telecentric lens, WD 288 mm 0.287xM58APS-H288±5 mm-71 MP$3,520.00 Ships in 3-4 weeks
LS-TCL-08950.325x bi-telecentric lens, WD 273 mm 0.325xM42APS-H273±5 mm7.671 MP$3,000.00 Ships in 3-4 weeks
LS-TCL-08720.229x bi-telecentric lens, WD 318 mm 0.229xM42APS-H318±5 mm6.571 MP$3,850.00 Ships in 3-4 weeks
LS-TCL-09010.39x bi-telecentric lens, WD 258 mm 0.39xF-mountAPS-H258±4 mmF9.271 MP$1,870.00 Ships in 3-4 weeks
LS-TCL-09110.488x bi-telecentric lens, WD 228 mm 0.488xF-mountAPS-H228±4 mmF6.671 MP$1,870.00 Ships in 3-4 weeks
LS-TCL-09520.813x bi-telecentric lens, WD 128 mm 0.813xF-mountAPS-H128±3 mmF22.971 MP$1,870.00 Ships in 3-4 weeks
LS-TCL-09290.696x bi-telecentric lens, WD 128 mm 0.696xF-mountAPS-H128±3 mmF13.171 MP$1,980.00 Ships in 3-4 weeks
LS-TCL-09220.542x bi-telecentric lens, WD 178 mm 0.542xF-mountAPS-H178±3 mmF11.571 MP$1,870.00 Ships in 3-4 weeks
LS-TCL-08970.355x bi-telecentric lens, WD 263 mm 0.355xM42APS-H263±4 mm8.371 MP$1,870.00 Ships in 3-4 weeks
LS-TCL-09711.083x bi-telecentric lens, WD 110 mm 1.083xF-mountAPS-H110±2 mmF18.371 MP$1,815.00 Ships in 3-4 weeks
LS-TCL-09070.433x bi-telecentric lens, WD 208 mm 0.433xF-mountAPS-H208±3 mmF10.271 MP$1,870.00 Ships in 3-4 weeks
LS-TCL-09510.813x bi-telecentric lens, WD 128 mm 0.813xF-mountAPS-H128±3 mmF15.371 MP$1,925.00 Ships in 3-4 weeks
LS-TCL-09260.609x bi-telecentric lens, WD 158 mm 0.609xM42APS-H158±3 mm11.571 MP$2,090.00 Ships in 3-4 weeks
LS-TCL-09560.929x bi-telecentric lens, WD 118 mm 0.929xF-mountAPS-H118±3 mmF15.371 MP$1,925.00 Ships in 3-4 weeks
LS-TCL-08590.13x bi-telecentric lens, WD 465 mm 0.13xF-mountAPS-H465±6 mmF6.571 MP$9,020.00Quote Ships in 3-4 weeks
LS-TCL-12100.138x bi-telecentric lens, WD 410 mm, 2" 0.138xM42APS-H410±6 mm7.8-$7,315.00 Ships in 3-4 weeks
LS-TCL-12120.22x bi-telecentric lens, WD 300 mm, 2" 0.220xM42APS-H300±5 mm11.1-$3,850.00 Ships in 3-4 weeks
LS-TCL-12110.174x bi-telecentric lens, WD 330 mm, 2" 0.174xM42APS-H330±5 mm7.8-$4,280.00 Ships in 3-4 weeks
LS-TCL-12140.275x bi-telecentric lens, WD 273 mm, 2" 0.275xF-mountAPS-H273±5 mmF7.8-$3,585.00 Ships in 3-4 weeks
