Hikrobot MV-SC3016C-06M-WBN SC3000 series vision sensor, 1.6MP, Color, 6mm focal length
  • Hikrobot MV-SC3016C-06M-WBN SC3000 series vision sensor, 1.6MP, Color, 6mm focal length
  • MV-SC3016C-06M-WBN dimensions (mm)

Smart cameras & vision sensors

Hikrobot MV-SC3016C-06M-WBN SC3000 series vision sensor, 1.6MP, Color, 6mm focal length

Model MV-SC3016C-06M-WBNHikrobot

  • Resolution1408 × 1024
  • SensorCMOS, global shutter
  • InterfaceFast Ethernet (100 Mbit/s)
  • Speed60 fps
  • Lens mountM12
  • Mono / colourColor
$1,809.00

Ships in 2-3 weeks

0.49 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Available in the US - comparable models:

Ask an engineerBrowse Smart cameras & vision sensors

MV-SC3016C-06M-WBN: resolution 1408 x 1024; sensor type CMOS, global shutter; sensor size 1/2.9"; max. frame rate 60 fps; mono/color Color.

Hikrobot MV-SC3016C-06M-WBN SC3000 series vision sensor, 1.6MP, Color, 6mm focal length. Adopts embedded hardware platform for high-speed image processing. Adopts built-in positioning and measurement algorithms to detect object's existence, quantity, location, etc.

  • Tracked worldwide shippingTracked UPS or DHL
  • 3-year warranty, minimumCovers defects in materials and workmanship
  • Expert machine-vision support includedFrom our engineering team, incl. a licensed P.E.
  • Volume discounts and Net 30For approved business accounts; purchase orders welcome
  • 90-day returnsUnused items, counted from delivery; free US return label; no restocking fee
  • Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Certifications (as printed)CEKC

Specifications

General

ModelMV-SC3016C-06M-WBN
BrandHikrobot
Vision toolMeasurement: P2P measurement, P2L measurement, contrast measurement, grayscale size, edge width measurement, width measurement, brightness average value, L2L angle, color measurement, color size, diameter measurement, line angle; Existence: Spot existence, edge existence, contour existence, pattern existence, circle existence, line existence, anomaly judge, existence detection; Count: Spot count, edge count, contour count, pattern count, learning-based count, color count; Recognition: Multi-object count, code recognition, color contrast, color recognition, category recognition, classification registration, object registration, OCR, learning-based OCR, character horizontal stripe detection; Logic: Calculator, if module, logic judge, format output, condition judge, character comparison, combination judge; Location: Calibration convert, single point alignment, point rectify, point grasp, scale transformation, fixture; Deep learning: DL classification, DL object detection; Defect detection: Anomaly detection; Industry tools: OCR and defect detection
Solution capacitySupports importing and exporting project, up to 32 projects can be stored
Lens capTransparent lens cap by default. Half-polarized or fully-polarized lens cap is optional.
IndicatorPower indicator (PWR), network indicator (LNK), status indicator (STS), result indicator (OK/NG)

Optics

Focal length6 mm

Sensor and imaging

Sensor typeCMOS, global shutter
Pixel size3.45 μm × 3.45 μm
Sensor size1/2.9"
Resolution1408 × 1024
Max. frame rate60 fps
Gain0 dB to 15 dB
Exposure time16 μs to 1 sec;35 μs to 1 sec
Pixel formatRGB 8, Mono 8
Mono/colorColor

Interfaces and I/O

Communication protocolRS-232, TCP, UDP, FTP, PROFINET, Modbus, EtherNet/IP, MELSEC/SLMP, FINS, Keyence KV
Data interfaceFast Ethernet (100 Mbit/s)
Digital I/O17-pin M12 connector provides power, Ethernet, digital I/O, and serial port: Input signal × 2 (Line 0/1), output signal × 3 (Line 5/6/7), bi-directional I/O × 3 (Line 2/3/4), and external button input × 1. Output signal can be set as NPN or PNP.
Client softwareSCMVS

Light

Light source14 LEDs, white light by default. Red, blue or IR is optional.

Environment and compliance

Ingress protectionIP67 (under proper installation of lens and wiring)
TemperatureWorking temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity20% RH to 95% RH (no condensation)
Vibration resistanceMeets standard IEC 60068-2-6:2007.; Bare device withstands 10 Hz to 55 Hz, 1.5 mm peak-to-peak amplitude, 2 hours per axis (X, Y, Z)
Shock resistanceMeets standard IEC 60068-2-27:2008.; Bare device withstands 30 g / 11 ms, half-sine wave, 500 shocks per axis (6 directions)
CertificationCE, KC

Electrical

Power supply24 VDC
Power consumptionAvg.: 13.8 W @ 24 VDC (light source enabled); Max.: 42 W @ 24 VDC (light source enabled)

Mechanical

Lens mountM12-mount, mechanical focus supported
Dimension65.2 mm × 65.2 mm × 47 mm (2.6" × 2.6" × 1.9")
WeightApprox. 280 g (0.6 lb.)
Shipping weight (estimated)0.49 kg

Engineering data

The MV-SC3016C-06M-WBN at a glance

The numbers that set this model apart, taken from its own printed specifications.

Resolution1408 × 1024 px
Max. frame rate60 fps
Focal length6 mm
Ingress protectionIP67
Power consumption13.8 Wavg. at 24 V DC; max. 42 W
ShutterGlobal
