Hikrobot CY-SCD120M-00C-NNN 12 MP mono smart camera

Smart cameras & vision sensors

Hikrobot MV-HD6-C1200M-NNN Smart camera, 12MP, Mono, Type-C port, Without lens and light

Model MV-HD6-C1200M-NNNHikrobot

Resolution4096 × 2944
SensorCMOS, global shutter
InterfaceGigabit Ethernet(1000 Mbit/s)
Speed45 fps
Lens mountC-mount
Mono / colourMono

$3,269.00

Quote

Quoted price: add to quote for lead time and volume pricing.

Ships in 2-3 weeks

0.84 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-HD6-C1200M-NNN Smart camera, 12MP, Mono, Type-C port, Without lens and light. Embedded AI deep-learning algorithms for character recognition, object recognition, defect detection and more Integrated VM algorithm platform software with free use of 140+ algorithm functions

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-HD6-C1200M-NNN
Brand	Hikrobot
Function module	Vision Master Platform (include deep learning module)
Lens cap	Transparent lens cap
Indicator	Power indicator (PWR), network indicator (LNK), status indictor (STS), and user-defined indicator (U1/U2)

Sensor and imaging

Sensor type	CMOS, global shutter
Pixel size	3.45 μm×3.45 μm
Sensor size	1.1"
Resolution	4096 × 2944
Max. frame rate	45 fps
Gain	0 dB ~ 37 dB
Exposure time	45 μs ~ 1 sec
Pixel format	Mono 8
Mono/color	Mono

Interfaces and I/O

Communication protocol	TCP, UDP, MODBUS, Serial Port, PROFINET, EtherNet/IP, Fins, MC, FTP, etc.
Data interface	Gigabit Ethernet(1000 Mbit/s)
Digital I/O	17-pin M12 connector provides power and I/O, including opto-isolated input × 2 (Line 0/1), opto-isolated output × 2 (Line 4/5), configurable non-isolated input/output × 2 (Line 2/3), RS-232 × 1, and light source output (max. 30 W) × 1
Extended interface	VGA × 1, and USB host × 1

Light

Light source	Not included

Environment and compliance

Ingress protection	IP67 (under proper installation of waterproof lens cap)
Temperature	Working temperature: 0 °C to 50 °C (32 °F to 122 °F); Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	20% RH to 95% RH (no condensation)
Certification	CE, KC

Computing

Memory	8 GB
Storage	64 GB

Electrical

Power supply	24 VDC
Power consumption	12.5 W@24 VDC (without external fill light); 42.5 W@24 VDC (with external fill light)

Mechanical

Lens mount	C-Mount
Dimension	116.3mm × 68.6mm × 101.8mm
Weight	Approx. 530 g (1.2 lb.)
Shipping weight (estimated)	0.84 kg

Downloads

Datasheet (PDF, Chinese)MV-HD6-C1200M-NNN · 2.3 MB

Features

Embedded AI deep-learning algorithms for character recognition, object recognition, defect detection and more
Integrated VM algorithm platform software with free use of 140+ algorithm functions
Extensive interface expansion: multiple I/O, direct light drive, display output and more
High-performance processor for faster, more efficient processing
Supports multiple industrial protocols for easy integration
Comprehensive status indicators show device status in real time for easy setup and maintenance
IP67 protection for harsh industrial environments
