Frame grabbers

Hikrobot MV-GS1104F XoF SFP+ Frame Grabbers, 4 ports, 40G bandwidth

Model MV-GS1104FHikrobot

InterfacePCI-E gen3 × 8
Ports4 ports
On-board memory4 GB DDR4
SFP+ moduleSFP+ × 4

$2,059.00

Ships in 2-3 weeks

0.38 kg shipping weight

Not available in the United States. Available for delivery to other countries.

Hikrobot MV-GS1104F XoF SFP+ Frame Grabbers, 4 ports, 40G bandwidth. Supports XoFLink protocol with multiple fiber ports to transmit data. Utilizes an interconnect of PCI-E gen3 × 8 to support image capture from 4 cameras simultaneously at a speed of 10 Gbps.

Same-day shipping on stock itemsTracked UPS or DHL
3-year warranty, minimumCovers defects in materials and workmanship
Expert machine-vision support includedFrom our licensed P.E. engineers
Volume discounts and Net 30For approved business accounts; purchase orders welcome
90-day returnsUnused items; free return label in the US
Secure checkout by ShopifyCard, PayPal, Shop Pay or Google Pay

Specifications

General

Model	MV-GS1104F
Brand	Hikrobot
Interconnect	PCI-E gen3 × 8
Indicator	1
Standard	XoFLink
SFP+ module	SFP+ × 4
Camera quantity supported	1/2/3/4
Camera connection speed	10 Gbps for single port, 40 Gbps in total
Stream	4

Interfaces and I/O

Data interface	2LC fiber port
I/O Type	Provides 11 configurable I/O connectors, compatible with single-ended/differential signals, and supports cascading of multiple frame grabbers.; ● I/O on bracket: Line 0 to Line 7 supports input and output (3.3 V to 24 V); ● I/O on PCB: Line 8 to Line 10 supports input (3.3 V to 12 V) and output (3.3 V)
Connector	Connector of I/O on bracket: 20-pin MiniDP female connector; Connector of I/O on PCB: 9-pin header (2.54 mm interval, 2 x 5, 10-pin hole)
Client software	MVS

Light

LED indicator	4

Environment and compliance

Temperature	Working temperature: 0 °C to 60 °C (32 °F to 140 °F); Storage temperature: –20 °C to 70 °C (–4 °F to 158 °F)
Humidity	10% RH to 95% RH (no condensation)
Certification	CE, KC, RoHS

Computing

On-board memory	4 GB DDR4
Operating system	Windows 7/10/11, Ubuntu 16.04 to 20.04 on Linux

Electrical

Power consumption	Typ. 20 W

Mechanical

Delivery bandwidth	7800 MB/s (max. transmission bandwidth); 6700 MB/s (sustained transmission bandwidth)
Dimension	181 mm × 126.3 mm × 21.6 mm (7.1" × 5.0" × 0.9")
Shipping weight (estimated)	0.38 kg

Downloads

Features

Supports XoFLink protocol with multiple fiber ports to transmit data.
Utilizes an interconnect of PCI-E gen3 × 8 to support image capture from 4 cameras simultaneously at a speed of 10 Gbps.
Various indicators indicate frame grabber status in real time.
Adopts multiple I/O connectors for input and output.
Provides SDK for secondary development.

Complete the station

The configurator matches a camera, lens, light, light controller and cables to each other, and to this part.

Build a system with this part Configure a system Ask an engineer

Other models in the XoF Frame Grabbers series

See all 8 models

Model	Size / key data	Price	Availability	Link
MV-GS1002F V3.0	XoFLink	$2,059.00	5 in stock	View
MV-GS1004F V3.0	XoFLink	$2,059.00	4 in stock	View
MV-GS1104F-CR	XoFLink	$2,059.00	3 in stock	View
MV-GS1104F-DF	XoFLink	$2,059.00	2 in stock	View
MV-GS1002F-DF V3.0	XoFLink	$2,059.00	4 in stock	View
MV-GS1004F-DF V3.0	XoFLink	$2,059.00	2 in stock	View
MV-GD1104	XoFLink	$2,059.00 Quote	Ships in 2-3 weeks	View
